JDM Vehicle Catalog

Vehicle Specs

ALFA ROMEO ALFA 147 1.6 TWIN SPARK SPORTIVAII

ALFA ROMEO ALFA 147

937BXB · 1.6 TWIN SPARK SPORTIVAII

Description

Modification: 1.6 TWIN SPARK SPORTIVAII
Chassis ID: 937BXB
Dates releasing: 2008.8~
Base price, ¥: ABA-937BXB
Body size: 4225x1730x1450
Interior (LxWxH): ----x----x----
Wheelbase: 2545
Track f/r: 1510mm/1495mm
Full weight, kg: 1240
Body type: Hatch
Doors / seats: 5 door / 5

Safe equipment

Driver's air bag: ✓
Front passenger air bag: ✓
Side airbags: ✓
ABS: ✓
TRC: ×
Belts w/ tensioner: ✓
Belts w/ effort limiter: ×
Belts w/ holding: ✓
Child-seat fixation: ×
Safety planks: ✓
Brake assist: ×
Energy-absorbing body: ×
EBD: ✓
Anti-theft device: ✓
Additional equipment: ASR(アンチスリップレギュレーション) FPS(火災防止装置)

Comfort

Air conditioner: Full Auto
Power window: ✓
Central switch: ✓
Steering column length: ✓
Steering column height: ✓
Cruise control: ×
Leather steering wheel: ×
Leather seats: —
Power front seat: ×
Power rear seat: ×
Wood panel: ×
Sunroof: ×
Alloy wheels: 17 inches standard
Folding seat: split
Glass w/ UV filter: ×
Toned glasses: ✓

Engine

Model: 32104
Type: inline 4 cylinder DOHC 16-valves
Bore x stroke, mm: 82.0x75.6
Engine size, cc: 1596
Compression ratio: 10.3
Fuel injection: 電子制御燃料噴射
Max power, hp/rpm: 120ps(88kW)/6200rpm
Max torque, Nm/rpm: 14.9kg m(146N m)/4200rpm
Supercharger: ×
Fuel tank, liters: 60 l
Fuel: Unleaded premium gasoline
Fuel consumption, l/100km: 0

Steering & suspension

Steering: Power assist equipped rack&pinion
Front suspension: Double wishbone ( Coil spring )
Rear suspension: McPherson Strut ( Coil spring )
Front brake: Ventilated disk
Rear brake: disk
Front wheel: 215/45R17
Rear wheel: 215/45R17
Min turn diameter, m: ----

Gearbox

Number of stages: 5MT
Drive: FF
LSD: ----

Exterior equipment

Front fog lights: ✓
Rear fog lights: ✓
Xenon: ✓
Extra front lights: ×
Spoilers (f / r): × / ✓
Wiper: ✓

Navigation & sound

Navigation: ×
Navigation device: It is not
Audio: AM/FMラジオ
CD player: 単装

Gear ratios

CVT	1	2	3	4	5	6	7	Rev	Main
—	3.909	2.238	1.520	1.156	0.919	—	—	—	3.909

Available colors

blackwhitegreenMaroon (brown)OliveNavy bluePurpleAshesYellowYellow-greenBlack (P)MagentaSilverRedBlueDark cyanPearlGold
