JDM Vehicle Catalog

Vehicle Specs

ALFA ROMEO GIULIETTA SPORTIVA FREE DRIVE EDITION

ALFA ROMEO GIULIETTA

940141 · SPORTIVA FREE DRIVE EDITION

Description

Modification: SPORTIVA FREE DRIVE EDITION
Chassis ID: 940141
Dates releasing: 2016.2~
Base price, ¥: ABA-940141
Body size: 4350x1800x1460
Interior (LxWxH): ----x----x----
Wheelbase: 2635
Track f/r: 1555mm/1555mm
Full weight, kg: 1400
Body type: Hatch
Doors / seats: 5 door / 5

Safe equipment

Driver's air bag: ✓
Front passenger air bag: ✓
Side airbags: ✓
ABS: ✓
TRC: ✓
Belts w/ tensioner: ✓
Belts w/ effort limiter: ✓
Belts w/ holding: ✓
Child-seat fixation: ×
Safety planks: ✓
Brake assist: ✓
Energy-absorbing body: ×
EBD: ✓
Anti-theft device: ✓
Additional equipment: ESC(エレクトロニックスタビリティコントロール) CBC(コーナリングブレーキ &

Comfort

Air conditioner: Full Auto
Power window: ✓
Central switch: ✓
Steering column length: ✓
Steering column height: ✓
Cruise control: ×
Leather steering wheel: ✓
Leather seats: —
Power front seat: ✓
Power rear seat: ×
Wood panel: ×
Sunroof: ×
Alloy wheels: 18 inches standard
Folding seat: split
Glass w/ UV filter: ×
Toned glasses: ✓

Engine

Model: 940A2
Type: inline 4 cylinder 16-valves IC-turbo
Bore x stroke, mm: 72.0x84.0
Engine size, cc: 1368
Compression ratio: 9.8
Fuel injection: マルチポイント type 電子制御燃料噴射
Max power, hp/rpm: 170ps(125kW)/5500rpm
Max torque, Nm/rpm: 23.5kg m(230N m)/2250rpm
Supercharger: IC turbo
Fuel tank, liters: 60 l
Fuel: Unleaded premium gasoline
Fuel consumption, l/100km: 6.4

Steering & suspension

Steering: Power assist equipped rack&pinion
Front suspension: McPherson Strut (stabilizer attaching)
Rear suspension: マルチリンク (stabilizer attaching)
Front brake: Ventilated disk
Rear brake: disk
Front wheel: 225/40R18
Rear wheel: 225/40R18
Min turn diameter, m: 5.5

Gearbox

Number of stages: 6AT
Drive: FF
LSD: ----

Exterior equipment

Front fog lights: ✓
Rear fog lights: ✓
Xenon: ✓
Extra front lights: ×
Spoilers (f / r): × / ✓
Wiper: ✓

Navigation & sound

Navigation: ✓
Navigation device: メモ
Audio: It is not
CD player: ×

Gear ratios

CVT	1	2	3	4	5	6	7	Rev	Main
—	4.154	2.269	1.435	0.978	0.754	0.622	—	—	4.000

Available colors

blackwhitegreenMaroon (brown)OliveNavy bluePurpleAshesYellowYellow-greenBlack (P)MagentaSilverRed / Other RedBlueDark cyanPearlGold
