AUDI 100 AVANT 2.8E

AUDI 100 AVANT

4AAAH · 2.8E

Description

Modification: 2.8E
Chassis ID: 4AAAH
Dates releasing: 1993.11~
Base price, ¥: E-4AAAH
Body size: 4795x1785x1470
Interior (LxWxH): ----x----x----
Wheelbase: 2685
Track f/r: 1525mm/1525mm
Full weight, kg: 1560
Body type: Wagon
Doors / seats: 5 door / 5

Safe equipment

Driver's air bag: ✓
Front passenger air bag: ×
Side airbags: ×
ABS: ✓
TRC: ×
Belts w/ tensioner: ✓
Belts w/ effort limiter: ×
Belts w/ holding: ✓
Child-seat fixation: ×
Safety planks: ✓
Brake assist: ×
Energy-absorbing body: ×
EBD: ×
Anti-theft device: ×
Additional equipment: EDS(エレクトロニックディファレンシャルロックシステム)

Comfort

Air conditioner: Full Auto
Power window: ✓
Central switch: ✓
Steering column length: ×
Steering column height: ×
Cruise control: ✓
Leather steering wheel: ✓
Leather seats: —
Power front seat: ×
Power rear seat: ×
Wood panel: ✓
Sunroof: ◯
Alloy wheels: 15 inches standard
Folding seat: split
Glass w/ UV filter: ×
Toned glasses: ×

Engine

Model: AAH
Type: water cooling V-type 6 cylinder SOHC
Bore x stroke, mm: 82.5x86.4
Engine size, cc: 2771
Compression ratio: 10.3
Fuel injection: MPI
Max power, hp/rpm: 170ps(----kW)/5500rpm
Max torque, Nm/rpm: 25.5kg m(----N m)/3000rpm
Supercharger: ×
Fuel tank, liters: 80 l
Fuel: Unleaded premium gasoline
Fuel consumption, l/100km: 14.7

Steering & suspension

Steering: Other
Front suspension: McPherson Strut (スタビライザーバー付)
Rear suspension: トーションビームトレーリングア&#12540
Front brake: Ventilated disk
Rear brake: disk
Front wheel: 195/65VR15
Rear wheel: 195/65VR15
Min turn diameter, m: 5.3

Gearbox

Number of stages: 4AT
Drive: FF
LSD: ----

Exterior equipment

Front fog lights: ✓
Rear fog lights: ✓
Xenon: ×
Extra front lights: ×
Spoilers (f / r): × / ✓
Wiper: ×

Navigation & sound

Navigation: ×
Navigation device: It is not
Audio: AM/FM radio with CS player
CD player: 連装

Gear ratios

CVT	1	2	3	4	5	6	7	Rev	Main
—	2.580	1.407	1.000	0.742	—	—	—	—	2.882

Available colors

blackwhitegreenMaroon (brown)OliveNavy bluePurple / Other PurpleAshesYellowYellow-greenBlack (P)MagentaSilver / Other SilverRedBlueDark cyan / Other Dark cyanPearlGold
