AUDI A6 AVANT 2.8 QUATTRO

AUDI A6 AVANT

4AACKF · 2.8 QUATTRO

Description

Modification: 2.8 QUATTRO
Chassis ID: 4AACKF
Dates releasing: 1996.10~
Base price, ¥: E-4AACKF
Body size: 4795x1785x1470
Interior (LxWxH): ----x----x----
Wheelbase: 2685
Track f/r: 1525mm/1525mm
Full weight, kg: 1670
Body type: Wagon
Doors / seats: 5 door / 5

Safe equipment

Driver's air bag: ✓
Front passenger air bag: ✓
Side airbags: ×
ABS: ✓
TRC: ×
Belts w/ tensioner: ×
Belts w/ effort limiter: ×
Belts w/ holding: ✓
Child-seat fixation: ×
Safety planks: ✓
Brake assist: ×
Energy-absorbing body: ×
EBD: ×
Anti-theft device: ✓
Additional equipment: EDS(エレクトロニックディファレンシャルロックシステム)

Comfort

Air conditioner: Full Auto
Power window: ✓
Central switch: ✓
Steering column length: ✓
Steering column height: ✓
Cruise control: ×
Leather steering wheel: ✓
Leather seats: —
Power front seat: ✓
Power rear seat: ×
Wood panel: ✓
Sunroof: ◯
Alloy wheels: 15 inches standard
Folding seat: split
Glass w/ UV filter: ×
Toned glasses: ×

Engine

Model: ACK
Type: water cooling V-type 6 cylinder DOHC 30-valves
Bore x stroke, mm: 82.5x86.4
Engine size, cc: 2771
Compression ratio: 10.6
Fuel injection: 電子 type (モトロニック)
Max power, hp/rpm: 193ps(142kW)/6000rpm
Max torque, Nm/rpm: 28.6kg m(280N m)/3200rpm
Supercharger: ×
Fuel tank, liters: 80 l
Fuel: Unleaded premium gasoline
Fuel consumption, l/100km: 11.5

Steering & suspension

Steering: Power assist equipped rack&pinion
Front suspension: McPherson Strut
Rear suspension: トラピジアムアーム
Front brake: Ventilated disk
Rear brake: disk
Front wheel: 205/60R15
Rear wheel: 205/60R15
Min turn diameter, m: 5.3

Gearbox

Number of stages: 4AT
Drive: Full-time 4WD
LSD: ✓

Exterior equipment

Front fog lights: ✓
Rear fog lights: ✓
Xenon: ×
Extra front lights: ✓
Spoilers (f / r): × / ✓
Wiper: ×

Navigation & sound

Navigation: ×
Navigation device: It is not
Audio: AM/FM radio with CS player
CD player: ×

Gear ratios

CVT	1	2	3	4	5	6	7	Rev	Main
—	2.580	1.407	1.000	0.742	—	—	—	—	2.882

Available colors

blackwhitegreenMaroon (brown) / Other Maroon (brown)OliveNavy blue / Other Navy bluePurpleAshesYellowYellow-greenBlack (P)MagentaSilver / Other SilverRedBlueDark cyan / Other Dark cyanPearlGold
