AUDI ALLROAD QUATTRO 4.2

AUDI ALLROAD QUATTRO

4BBASF · 4.2

Description

Modification: 4.2
Chassis ID: 4BBASF
Dates releasing: 2004.4~
Base price, ¥: GH-4BBASF
Body size: 4815x1865x1530
Interior (LxWxH): ----x----x----
Wheelbase: 2760
Track f/r: 1595mm/1600mm
Full weight, kg: 1900
Body type: SUV
Doors / seats: 5 door / 5

Safe equipment

Driver's air bag: ✓
Front passenger air bag: ✓
Side airbags: ✓
ABS: ✓
TRC: ✓
Belts w/ tensioner: ×
Belts w/ effort limiter: ✓
Belts w/ holding: ✓
Child-seat fixation: ✓
Safety planks: ✓
Brake assist: ✓
Energy-absorbing body: ×
EBD: ✓
Anti-theft device: ✓
Additional equipment: ESP(エレクトロニックスタビリティ PRO グラム)/EDS(エレクトリックデファレン&#1247

Comfort

Air conditioner: Full Auto
Power window: ✓
Central switch: ✓
Steering column length: ✓
Steering column height: ✓
Cruise control: ✓
Leather steering wheel: ✓
Leather seats: —
Power front seat: ✓
Power rear seat: ×
Wood panel: ✓
Sunroof: ◯
Alloy wheels: 18 inches standard
Folding seat: split
Glass w/ UV filter: ×
Toned glasses: ×

Engine

Model: BAS
Type: V-type 8 cylinder DOHC 40-valves
Bore x stroke, mm: 84.5x92.8
Engine size, cc: 4163
Compression ratio: 11.0
Fuel injection: 電子
Max power, hp/rpm: 300ps(220kW)/6200rpm
Max torque, Nm/rpm: 38.8kg m(380N m)/2700~4600rpm
Supercharger: ×
Fuel tank, liters: 70 l
Fuel: Unleaded premium gasoline
Fuel consumption, l/100km: 0

Steering & suspension

Steering: Power assist equipped rack&pinion
Front suspension: 4リンク+スタビライザーバー
Rear suspension: Double wishbone +スタビライザーバー
Front brake: Ventilated disk
Rear brake: disk
Front wheel: 245/45R18
Rear wheel: 245/45R18
Min turn diameter, m: ----

Gearbox

Number of stages: 5AT
Drive: Full-time 4WD
LSD: ----

Exterior equipment

Front fog lights: ✓
Rear fog lights: ✓
Xenon: ✓
Extra front lights: ×
Spoilers (f / r): × / ×
Wiper: ✓

Navigation & sound

Navigation: ✓
Navigation device: DVD
Audio: AM/FM radio with MD player
CD player: 連装

Gear ratios

CVT	1	2	3	4	5	6	7	Rev	Main
—	3.664	1.998	1.406	1.000	0.742	—	—	—	4.095

Available colors

black / Other blackwhitegreen / Other greenMaroon (brown) / Other Maroon (brown)OliveNavy blue / Other Navy bluePurpleAshes / Other AshesYellowYellow-greenBlack (P)MagentaSilver / Other SilverRedBlueDark cyanPearlGold / Other Gold
