AUDI RS Q3 BASE GRADE

AUDI RS Q3

8UCZGF · BASE GRADE

Description

Modification: BASE GRADE
Chassis ID: 8UCZGF
Dates releasing: 2015.5~
Base price, ¥: ABA-8UCZGF
Body size: 4410x1840x1595
Interior (LxWxH): ----x----x----
Wheelbase: 2605
Track f/r: 1585mm/1590mm
Full weight, kg: 1700
Body type: SUV
Doors / seats: 5 door / 5

Safe equipment

Driver's air bag: ✓
Front passenger air bag: ✓
Side airbags: ✓
ABS: ✓
TRC: ×
Belts w/ tensioner: ✓
Belts w/ effort limiter: ✓
Belts w/ holding: ✓
Child-seat fixation: ×
Safety planks: ✓
Brake assist: ✓
Energy-absorbing body: ×
EBD: ✓
Anti-theft device: ✓
Additional equipment: ESC(エレクトロニックスタビリゼーションコントロール)

Comfort

Air conditioner: Full Auto
Power window: ✓
Central switch: ×
Steering column length: ×
Steering column height: ×
Cruise control: ✓
Leather steering wheel: ✓
Leather seats: —
Power front seat: ✓
Power rear seat: ×
Wood panel: ×
Sunroof: ◯
Alloy wheels: 20 inches standard
Folding seat: ×
Glass w/ UV filter: ×
Toned glasses: ◯

Engine

Model: CZG
Type: inline 5 cylinder DOHCIC-turbo
Bore x stroke, mm: 82.5x92.8
Engine size, cc: 2480
Compression ratio: 10.0
Fuel injection: 電子
Max power, hp/rpm: 340ps(250kW)/5300~6800rpm
Max torque, Nm/rpm: 45.9kg m(450N m)/1600~5300rpm
Supercharger: IC turbo
Fuel tank, liters: 63 l
Fuel: Unleaded premium gasoline
Fuel consumption, l/100km: 7.7

Steering & suspension

Steering: Power assist equipped rack&pinion
Front suspension: McPherson Strut
Rear suspension: ウィッシュボーン
Front brake: Ventilated disk
Rear brake: Ventilated disk
Front wheel: 255/35R20
Rear wheel: 255/35R20
Min turn diameter, m: 5.7

Gearbox

Number of stages: 7AT
Drive: Full-time 4WD
LSD: ----

Exterior equipment

Front fog lights: ×
Rear fog lights: ✓
Xenon: ×
Extra front lights: ×
Spoilers (f / r): ✓ / ✓
Wiper: ✓

Navigation & sound

Navigation: ✓
Navigation device: HDD
Audio: AM/FMラジオ
CD player: 単装

Gear ratios

CVT	1	2	3	4	5	6	7	Rev	Main
—	3.562	2.526	1.678	1.021	0.788	0.760	0.634	—	2.789

Available colors

black / Mythos Black Metallicwhite / Other white / Glacier White MetallicgreenMaroon (brown)OliveNavy bluePurpleAshes / Other AshesYellowYellow-greenBlack (P) / Other Black (P)MagentaSilver / Other SilverRed / Other RedBlue / Other BlueDark cyanPearlGold
