BMW 3 SERIES ACTIVE HYBRID 3

BMW 3 SERIES

3F30 · ACTIVE HYBRID 3

Description

Modification: ACTIVE HYBRID 3
Chassis ID: 3F30
Dates releasing: 2012.7~
Base price, ¥: DAA-3F30
Body size: 4625x1800x1440
Interior (LxWxH): ----x----x----
Wheelbase: 2810
Track f/r: —
Full weight, kg: 1740
Body type: Sedan
Doors / seats: 4 door / 5

Safe equipment

Driver's air bag: ✓
Front passenger air bag: ✓
Side airbags: ✓
ABS: ✓
TRC: ✓
Belts w/ tensioner: ✓
Belts w/ effort limiter: ✓
Belts w/ holding: ✓
Child-seat fixation: ×
Safety planks: ✓
Brake assist: ✓
Energy-absorbing body: ×
EBD: ×
Anti-theft device: ✓
Additional equipment: DSC/ダイナミックスタビリティコントロール(拡張機能付) CBC/コーナリングブ&

Comfort

Air conditioner: Full Auto
Power window: ✓
Central switch: ✓
Steering column length: ✓
Steering column height: ✓
Cruise control: ✓
Leather steering wheel: ✓
Leather seats: —
Power front seat: ×
Power rear seat: ×
Wood panel: ×
Sunroof: ×
Alloy wheels: 17 inches standard
Folding seat: ×
Glass w/ UV filter: ×
Toned glasses: ×

Engine

Model: ----
Type: inline 6 cylinder DOHCturbo +
Bore x stroke, mm: ----x----
Engine size, cc: 2979
Compression ratio: ----
Fuel injection: デジタルモーターエレクトロニク&#1247
Max power, hp/rpm: 306ps(225kW)/5800rpm
Max torque, Nm/rpm: 40.8kg m(400N m)/1200~5000rpm
Supercharger: Turbo
Fuel tank, liters: ---- l
Fuel: Unleaded premium gasoline
Fuel consumption, l/100km: 0

Steering & suspension

Steering: Power assist equipped rack&pinion
Front suspension: ダブルウイッシュボーン type 、コイル
Rear suspension: インテグラルアーム type 、コイルスプ
Front brake: Ventilated disk
Rear brake: Ventilated disk
Front wheel: 225/50R17
Rear wheel: 225/50R17
Min turn diameter, m: ----

Gearbox

Number of stages: 8AT
Drive: FR
LSD: ----

Exterior equipment

Front fog lights: ✓
Rear fog lights: ×
Xenon: ✓
Extra front lights: ×
Spoilers (f / r): × / ×
Wiper: ×

Navigation & sound

Navigation: ✓
Navigation device: HDD
Audio: AM/FMラジオ
CD player: 単装

Gear ratios

CVT	1	2	3	4	5	6	7	Rev	Main
—	—	—	—	—	—	—	—	—	----

Available colors

blackwhitegreenMaroon (brown)OliveNavy bluePurpleAshesYellowYellow-greenBlack (P)MagentaSilverRedBlueDark cyanPearlGold
