BMW 3 SERIES ACTIVE HYBRID 3 M SPORT

BMW 3 SERIES

3F30 · ACTIVE HYBRID 3 M SPORT

Description

Modification: ACTIVE HYBRID 3 M SPORT
Chassis ID: 3F30
Dates releasing: 2013.8~
Base price, ¥: DAA-3F30
Body size: 4625x1810x1440
Interior (LxWxH): ----x----x----
Wheelbase: 2810
Track f/r: 1525mm/1540mm
Full weight, kg: 1740
Body type: Sedan
Doors / seats: 4 door / 5

Safe equipment

Driver's air bag: ✓
Front passenger air bag: ✓
Side airbags: ✓
ABS: ✓
TRC: ✓
Belts w/ tensioner: ✓
Belts w/ effort limiter: ✓
Belts w/ holding: ✓
Child-seat fixation: ×
Safety planks: ✓
Brake assist: ✓
Energy-absorbing body: ×
EBD: ×
Anti-theft device: ✓
Additional equipment: DSC/ダイナミックスタビリティコントロール(拡張機能付) CBC/コーナリングブ&

Comfort

Air conditioner: Dual air conditioning
Power window: ✓
Central switch: ✓
Steering column length: ✓
Steering column height: ✓
Cruise control: ✓
Leather steering wheel: ✓
Leather seats: —
Power front seat: ✓
Power rear seat: ×
Wood panel: ◯
Sunroof: ◯
Alloy wheels: 18 inches standard
Folding seat: split
Glass w/ UV filter: ◯
Toned glasses: ×

Engine

Model: N55B30A-M230
Type: inline 6 cylinder DOHCturbo +
Bore x stroke, mm: ----x----
Engine size, cc: 2979
Compression ratio: 10.2
Fuel injection: デジタルモーターエレクトロニク&#1247
Max power, hp/rpm: 306ps(225kW)/5800rpm
Max torque, Nm/rpm: 40.8kg m(400N m)/1200~5000rpm
Supercharger: Turbo
Fuel tank, liters: 57 l
Fuel: Unleaded premium gasoline
Fuel consumption, l/100km: 6.1

Steering & suspension

Steering: Power assist equipped rack&pinion
Front suspension: ダブル JOIN トスプリング Strut type 、コイル &#12
Rear suspension: 5-link 、 Coil spring 、スタビライザー付
Front brake: Ventilated disk
Rear brake: Ventilated disk
Front wheel: 225/45R18
Rear wheel: 255/40R18
Min turn diameter, m: 5.4

Gearbox

Number of stages: 8AT
Drive: FR
LSD: ----

Exterior equipment

Front fog lights: ✓
Rear fog lights: ✓
Xenon: ✓
Extra front lights: ×
Spoilers (f / r): × / ×
Wiper: ×

Navigation & sound

Navigation: ✓
Navigation device: HDD
Audio: AM/FMラジオ
CD player: 単装

Gear ratios

CVT	1	2	3	4	5	6	7	Rev	Main
—	4.714	3.143	2.106	1.667	1.285	1.000	0.839	0.667	3.317

Available colors

black / BLACK II / Black Sapphirewhite / Alpin White III / Other whitegreenMaroon (brown) / Other Maroon (brown)OliveNavy blue / Other Navy bluePurpleAshes / Other AshesYellowYellow-greenBlack (P) / Other Black (P)MagentaSilver / Other SilverRed / Other RedBlue / Other BlueDark cyanPearlGold
