BMW 7 SERIES ACTIVE HYBRID 7L

BMW 7 SERIES

YE30 · ACTIVE HYBRID 7L

Description

Modification: ACTIVE HYBRID 7L
Chassis ID: YE30
Dates releasing: 2015.2~
Base price, ¥: DAA-YE30
Body size: 5220x1900x1485
Interior (LxWxH): ----x----x----
Wheelbase: 3210
Track f/r: 1620mm/1630mm
Full weight, kg: 2100
Body type: Sedan
Doors / seats: 4 door / 5

Safe equipment

Driver's air bag: ✓
Front passenger air bag: ✓
Side airbags: ✓
ABS: ✓
TRC: ✓
Belts w/ tensioner: ✓
Belts w/ effort limiter: ✓
Belts w/ holding: ✓
Child-seat fixation: ×
Safety planks: ✓
Brake assist: ✓
Energy-absorbing body: ×
EBD: ×
Anti-theft device: ✓
Additional equipment: DSC/ダイナミックスタビリティコントロール(拡張機能付) CBC/コーナリングブ&

Comfort

Air conditioner: Dual air conditioning
Power window: ✓
Central switch: ✓
Steering column length: ✓
Steering column height: ✓
Cruise control: ✓
Leather steering wheel: ✓
Leather seats: —
Power front seat: ✓
Power rear seat: ◯
Wood panel: ◯
Sunroof: ◯
Alloy wheels: 18 inches standard
Folding seat: ×
Glass w/ UV filter: ×
Toned glasses: ×

Engine

Model: N55B30A-M230
Type: inline 6 cylinder DOHCturbo +
Bore x stroke, mm: ----x----
Engine size, cc: 2979
Compression ratio: 10.0
Fuel injection: デジタルモーターエレクトロニク&#1247
Max power, hp/rpm: 320ps(235kW)/5800rpm
Max torque, Nm/rpm: 45.9kg m(450N m)/1300~4500rpm
Supercharger: Turbo
Fuel tank, liters: 80 l
Fuel: Unleaded premium gasoline
Fuel consumption, l/100km: 7

Steering & suspension

Steering: Power assist equipped rack&pinion
Front suspension: ダブルウィッシュボーン type 、コイル
Rear suspension: インテグラルアーム type 、エアスプリ
Front brake: Ventilated disk
Rear brake: Ventilated disk
Front wheel: 245/50R18
Rear wheel: 245/50R18
Min turn diameter, m: 6.1

Gearbox

Number of stages: 8AT
Drive: FR
LSD: ----

Exterior equipment

Front fog lights: ✓
Rear fog lights: ✓
Xenon: ×
Extra front lights: ×
Spoilers (f / r): × / ×
Wiper: ×

Navigation & sound

Navigation: ✓
Navigation device: HDD
Audio: AM/FMラジオ
CD player: 単装

Gear ratios

CVT	1	2	3	4	5	6	7	Rev	Main
—	4.714	3.143	2.106	1.667	1.285	1.000	0.839	0.667	3.317

Available colors

black / Other blackwhite / Other whitegreenMaroon (brown) / Other Maroon (brown)OliveNavy blue / Other Navy bluePurpleAshes / Other AshesYellowYellow-greenBlack (P) / Other Black (P)MagentaSilver / Other SilverRedBlue / Other BlueDark cyanPearlGold / Other Gold
