BMW M3 COUPE

BMW M3

BL32 · COUPE

Description

Modification: COUPE
Chassis ID: BL32
Dates releasing: 2002.12~
Base price, ¥: GH-BL32
Body size: 4490x1780x1370
Interior (LxWxH): ----x----x----
Wheelbase: 2730
Track f/r: 1510mm/1525mm
Full weight, kg: 1560
Body type: Coupe
Doors / seats: 2 door / 5

Safe equipment

Driver's air bag: ✓
Front passenger air bag: ✓
Side airbags: ✓
ABS: ✓
TRC: ✓
Belts w/ tensioner: ✓
Belts w/ effort limiter: ×
Belts w/ holding: ✓
Child-seat fixation: ×
Safety planks: ✓
Brake assist: ×
Energy-absorbing body: ×
EBD: ×
Anti-theft device: ✓
Additional equipment: DSC(ダイナミックスタビリティコントロール)

Comfort

Air conditioner: Full Auto
Power window: ✓
Central switch: ✓
Steering column length: ✓
Steering column height: ✓
Cruise control: ×
Leather steering wheel: ✓
Leather seats: —
Power front seat: ✓
Power rear seat: ×
Wood panel: ×
Sunroof: ◯
Alloy wheels: 18 inches standard
Folding seat: split
Glass w/ UV filter: ×
Toned glasses: ×

Engine

Model: 32 6S4
Type: inline 6 cylinder DOHC 24-valves
Bore x stroke, mm: 87.0x91.0
Engine size, cc: 3246
Compression ratio: 11.5
Fuel injection: デジタルモーターエレクトロニク&#1247
Max power, hp/rpm: 343ps(252kW)/7900rpm
Max torque, Nm/rpm: 37.2kg m(365N m)/4900rpm
Supercharger: ×
Fuel tank, liters: 63 l
Fuel: Unleaded premium gasoline
Fuel consumption, l/100km: 12

Steering & suspension

Steering: Power assist equipped rack&pinion
Front suspension: シングル JOIN トスプリング Strut type
Rear suspension: セントラルアーム
Front brake: Ventilated disk
Rear brake: Ventilated disk
Front wheel: 225/45R18
Rear wheel: 255/40R18
Min turn diameter, m: 5.3

Gearbox

Number of stages: 6MT
Drive: FR
LSD: ----

Exterior equipment

Front fog lights: ✓
Rear fog lights: ✓
Xenon: ✓
Extra front lights: ×
Spoilers (f / r): ✓ / ✓
Wiper: ×

Navigation & sound

Navigation: ×
Navigation device: It is not
Audio: AM/FM radio with MD player
CD player: ×

Gear ratios

CVT	1	2	3	4	5	6	7	Rev	Main
—	4.227	2.528	1.669	1.226	1.000	0.827	—	—	3.746

Available colors

black / Other blackwhite / Alpin White IIIgreen / Other greenMaroon (brown)OliveNavy bluePurpleAshes / Other AshesYellow / Other YellowYellow-greenBlack (P) / Other Black (P)MagentaSilver / Other SilverRed / Other RedBlue / Other BlueDark cyanPearlGold
