JDM Vehicle Catalog

Vehicle Specs

CHEVROLET ASTRO LS

CHEVROLET ASTRO

CM14G · LS

Description

Modification: LS
Chassis ID: CM14G
Dates releasing: 2005.1~
Base price, ¥: GH-CM14G
Body size: 4805x1960x1930
Interior (LxWxH): 2655x1690x1210
Wheelbase: 2820
Track f/r: 1655mm/1655mm
Full weight, kg: 2020
Body type: MV 1Box
Doors / seats: 4 door / 8

Safe equipment

Driver's air bag: ✓
Front passenger air bag: ✓
Side airbags: ×
ABS: ✓
TRC: ×
Belts w/ tensioner: ×
Belts w/ effort limiter: ×
Belts w/ holding: ✓
Child-seat fixation: ×
Safety planks: ✓
Brake assist: ×
Energy-absorbing body: ×
EBD: ×
Anti-theft device: ✓
Additional equipment: ×

Comfort

Air conditioner: Manual
Power window: ✓
Central switch: ✓
Steering column length: ×
Steering column height: ✓
Cruise control: ✓
Leather steering wheel: ×
Leather seats: —
Power front seat: ✓
Power rear seat: ×
Wood panel: ×
Sunroof: ×
Alloy wheels: 16 inches standard
Folding seat: 一体
Glass w/ UV filter: ×
Toned glasses: ✓

Engine

Model: 4G
Type: water cooling V-type 6 cylinder
Bore x stroke, mm: 101.6x88.3
Engine size, cc: 4295
Compression ratio: 9.2
Fuel injection: 電子 type 燃料噴射(SFI)
Max power, hp/rpm: 193ps(142kW)/4400rpm
Max torque, Nm/rpm: 34.6kg m(339N m)/2800rpm
Supercharger: ×
Fuel tank, liters: 101 l
Fuel: Regular unleaded gasoline
Fuel consumption, l/100km: 0

Steering & suspension

Steering: Other
Front suspension: Double wishbone type Coil spring
Rear suspension: Axle リーフスプリング
Front brake: Ventilated disk
Rear brake: Ventilated disk
Front wheel: P215/70R16 99S
Rear wheel: P215/70R16 99S
Min turn diameter, m: 6.5

Gearbox

Number of stages: 4AT
Drive: FR
LSD: ----

Exterior equipment

Front fog lights: ×
Rear fog lights: ×
Xenon: ×
Extra front lights: ×
Spoilers (f / r): × / ×
Wiper: ✓

Navigation & sound

Navigation: ×
Navigation device: It is not
Audio: AM/FM radio with CS player
CD player: ×

Gear ratios

CVT	1	2	3	4	5	6	7	Rev	Main
—	3.058	1.625	1.000	0.696	—	—	—	—	2.294

Available colors

black / Other blackwhite / Other whitegreenMaroon (brown)OliveNavy bluePurpleAshes / Other AshesYellowYellow-greenBlack (P)MagentaSilverRedBlueDark cyanPearlGold / Other Gold
