JDM Vehicle Catalog

Vehicle Specs

CHRYSLER JEEP JEEP GRAND CHEROKEE LAREDO 4.7

CHRYSLER JEEP JEEP GRAND CHEROKEE

WH47 · LAREDO 4.7

Description

Modification: LAREDO 4.7
Chassis ID: WH47
Dates releasing: 2006.6~
Base price, ¥: GH-WH47
Body size: 4760x1880x1750
Interior (LxWxH): ----x----x----
Wheelbase: 2780
Track f/r: 1575mm/1575mm
Full weight, kg: 2100
Body type: SUV
Doors / seats: 5 door / 5

Safe equipment

Driver's air bag: ✓
Front passenger air bag: ✓
Side airbags: ×
ABS: ✓
TRC: ✓
Belts w/ tensioner: ✓
Belts w/ effort limiter: ✓
Belts w/ holding: ✓
Child-seat fixation: ×
Safety planks: ✓
Brake assist: ✓
Energy-absorbing body: ×
EBD: ✓
Anti-theft device: ✓
Additional equipment: エレクトロニックスタビリティー PRO グラム(ESP)

Comfort

Air conditioner: Manual
Power window: ✓
Central switch: ✓
Steering column length: ×
Steering column height: ✓
Cruise control: ✓
Leather steering wheel: ×
Leather seats: —
Power front seat: ✓
Power rear seat: ×
Wood panel: ×
Sunroof: ×
Alloy wheels: 17 inches standard
Folding seat: split
Glass w/ UV filter: ×
Toned glasses: ✓

Engine

Model: 661
Type: V-type 8 cylinder SOHC
Bore x stroke, mm: 93.0x86.5
Engine size, cc: 4700
Compression ratio: 9.0
Fuel injection: 電子 type 燃料噴射装置
Max power, hp/rpm: 231ps(170kW)/4500rpm
Max torque, Nm/rpm: 41.8kg m(410N m)/3600rpm
Supercharger: ×
Fuel tank, liters: 77 l
Fuel: Unleaded premium gasoline
Fuel consumption, l/100km: 16.4

Steering & suspension

Steering: Power assist equipped rack&pinion
Front suspension: Double wishbone
Rear suspension: コイルリジット
Front brake: Ventilated disk
Rear brake: disk
Front wheel: 245/65R17 107H
Rear wheel: 245/65R17 107H
Min turn diameter, m: 5.6

Gearbox

Number of stages: 5AT
Drive: Full-time 4WD
LSD: ----

Exterior equipment

Front fog lights: ✓
Rear fog lights: ✓
Xenon: ×
Extra front lights: ×
Spoilers (f / r): × / ×
Wiper: ✓

Navigation & sound

Navigation: ◯
Navigation device: HDD
Audio: AM/FMラジオ
CD player: 連装

Gear ratios

CVT	1	2	3	4	5	6	7	Rev	Main
—	3.000	1.667	1.000	0.750	0.670	—	—	—	3.000

Available colors

black / Other blackwhite / Other whitegreenMaroon (brown)OliveNavy bluePurpleAshesYellowYellow-greenBlack (P)MagentaSilverRedBlueDark cyanPearlGold
