CITROEN AX 14TRS

CITROEN AX

ZAKD · 14TRS

Description

Modification: 14TRS
Chassis ID: ZAKD
Dates releasing: 1991.10~
Base price, ¥: E-ZAKD
Body size: 3525x1555x1350
Interior (LxWxH): 1450x1320x1110
Wheelbase: 2280
Track f/r: 1370mm/1290mm
Full weight, kg: 810
Body type: Hatch
Doors / seats: 5 door / 5

Safe equipment

Driver's air bag: ×
Front passenger air bag: ×
Side airbags: ×
ABS: ×
TRC: ×
Belts w/ tensioner: ×
Belts w/ effort limiter: ×
Belts w/ holding: ✓
Child-seat fixation: ×
Safety planks: ×
Brake assist: ×
Energy-absorbing body: ×
EBD: ×
Anti-theft device: ×
Additional equipment: ×

Comfort

Air conditioner: Manual
Power window: ✓
Central switch: ✓
Steering column length: ×
Steering column height: ×
Cruise control: ×
Leather steering wheel: ×
Leather seats: —
Power front seat: ×
Power rear seat: ×
Wood panel: ×
Sunroof: ×
Alloy wheels: Option settings NO
Folding seat: split
Glass w/ UV filter: ×
Toned glasses: ×

Engine

Model: KD
Type: water cooling inline 4 cylinder OHC
Bore x stroke, mm: 75.0x77.0
Engine size, cc: 1360
Compression ratio: 9.3
Fuel injection: 電子制御燃料噴射装置
Max power, hp/rpm: 75ps(----kW)/6200rpm
Max torque, Nm/rpm: 11.3kg m(----N m)/4000rpm
Supercharger: ×
Fuel tank, liters: 43 l
Fuel: Unleaded premium gasoline
Fuel consumption, l/100km: 8.9

Steering & suspension

Steering: Power assist equipped rack&pinion
Front suspension: McPherson Strut
Rear suspension: トレーリングアーム
Front brake: disk
Rear brake: Drum
Front wheel: 155/70R13
Rear wheel: 155/70R13
Min turn diameter, m: 5.1

Gearbox

Number of stages: 5MT
Drive: FF
LSD: ----

Exterior equipment

Front fog lights: ×
Rear fog lights: ✓
Xenon: ×
Extra front lights: ×
Spoilers (f / r): ✓ / ×
Wiper: ✓

Navigation & sound

Navigation: ×
Navigation device: It is not
Audio: AM/FM radio with CS player
CD player: ×

Gear ratios

CVT	1	2	3	4	5	6	7	Rev	Main
—	3.416	1.809	1.275	0.975	0.767	—	—	—	3.584

Available colors

blackwhitegreen / Other greenMaroon (brown)OliveNavy blue / Other Navy bluePurpleAshesYellowYellow-greenBlack (P)MagentaSilver / Other SilverRed / Other RedBlueDark cyanPearlGold
