CITROEN C5 BREAK2.0

CITROEN C5

X4RFNW · BREAK2.0

Description

Modification: BREAK2.0
Chassis ID: X4RFNW
Dates releasing: 2002.10~
Base price, ¥: GH-X4RFNW
Body size: 4780x1770x1570
Interior (LxWxH): 1860x1535x1210
Wheelbase: 2750
Track f/r: 1545mm/1500mm
Full weight, kg: 1460
Body type: Wagon
Doors / seats: 5 door / 5

Safe equipment

Driver's air bag: ✓
Front passenger air bag: ✓
Side airbags: ✓
ABS: ✓
TRC: ×
Belts w/ tensioner: ✓
Belts w/ effort limiter: ✓
Belts w/ holding: ✓
Child-seat fixation: ×
Safety planks: ✓
Brake assist: ✓
Energy-absorbing body: ×
EBD: ✓
Anti-theft device: ✓
Additional equipment: ×

Comfort

Air conditioner: Full Auto
Power window: ✓
Central switch: ✓
Steering column length: ✓
Steering column height: ✓
Cruise control: ×
Leather steering wheel: ×
Leather seats: —
Power front seat: ×
Power rear seat: ×
Wood panel: ×
Sunroof: ◯
Alloy wheels: 15 inches standard
Folding seat: split
Glass w/ UV filter: ×
Toned glasses: ×

Engine

Model: RFN
Type: water cooling inline 4 cylinder DOHC
Bore x stroke, mm: 85.0x88.0
Engine size, cc: 1997
Compression ratio: 10.8
Fuel injection: 電子制御燃料噴射装置
Max power, hp/rpm: 137ps(100kW)/6000rpm
Max torque, Nm/rpm: 19.8kg m(190N m)/4100rpm
Supercharger: ×
Fuel tank, liters: 65 l
Fuel: Unleaded premium gasoline
Fuel consumption, l/100km: 0

Steering & suspension

Steering: Power assist equipped rack&pinion
Front suspension: McPherson Strut
Rear suspension: トレーリングアーム
Front brake: Ventilated disk
Rear brake: disk
Front wheel: 205/65R15
Rear wheel: 205/65R15
Min turn diameter, m: ----

Gearbox

Number of stages: 4AT
Drive: FF
LSD: ----

Exterior equipment

Front fog lights: ✓
Rear fog lights: ✓
Xenon: ×
Extra front lights: ×
Spoilers (f / r): × / ×
Wiper: ✓

Navigation & sound

Navigation: ×
Navigation device: It is not
Audio: AM/FMラジオ
CD player: 連装

Gear ratios

CVT	1	2	3	4	5	6	7	Rev	Main
—	3.510	1.931	1.288	0.915	—	—	—	—	3.166

Available colors

black / Other blackwhite / Other whitegreen / Other greenMaroon (brown)OliveNavy blue / Other Navy bluePurpleAshes / Other AshesYellowYellow-greenBlack (P) / Other Black (P)MagentaSilver / Other SilverRed / Other RedBlue / Other BlueDark cyan / Other Dark cyanPearlGold
