CITROEN CHANSON SX

CITROEN CHANSON

S8NF · SX

Description

Modification: SX
Chassis ID: S8NF
Dates releasing: 1997.2~
Base price, ¥: E-S8NF
Body size: 3720x1595x1380
Interior (LxWxH): 1625x1335x1120
Wheelbase: 2385
Track f/r: 1380mm/1315mm
Full weight, kg: 940
Body type: Hatch
Doors / seats: 3 door / 5

Safe equipment

Driver's air bag: ✓
Front passenger air bag: ✓
Side airbags: ×
ABS: ✓
TRC: ×
Belts w/ tensioner: ✓
Belts w/ effort limiter: ×
Belts w/ holding: ✓
Child-seat fixation: ×
Safety planks: ✓
Brake assist: ×
Energy-absorbing body: ×
EBD: ×
Anti-theft device: ×
Additional equipment: ×

Comfort

Air conditioner: Manual
Power window: ✓
Central switch: ✓
Steering column length: ×
Steering column height: ×
Cruise control: ×
Leather steering wheel: ×
Leather seats: —
Power front seat: ×
Power rear seat: ×
Wood panel: ×
Sunroof: ◯
Alloy wheels: Option settings NO
Folding seat: split
Glass w/ UV filter: ×
Toned glasses: ×

Engine

Model: NF
Type: water cooling inline 4 cylinder OHC
Bore x stroke, mm: 78.5x82.0
Engine size, cc: 1587
Compression ratio: 9.6
Fuel injection: 電子制御燃料噴射装置
Max power, hp/rpm: 90ps(66kW)/5600rpm
Max torque, Nm/rpm: 14.0kg m(137.3N m)/3000rpm
Supercharger: ×
Fuel tank, liters: 45 l
Fuel: Unleaded premium gasoline
Fuel consumption, l/100km: 8.9

Steering & suspension

Steering: Power assist equipped rack&pinion
Front suspension: McPherson Strut
Rear suspension: トレーリングアーム
Front brake: disk
Rear brake: Drum
Front wheel: 165/65R14 79H
Rear wheel: 165/65R14 79H
Min turn diameter, m: 5.5

Gearbox

Number of stages: 3AT
Drive: FF
LSD: ----

Exterior equipment

Front fog lights: ×
Rear fog lights: ✓
Xenon: ×
Extra front lights: ×
Spoilers (f / r): × / ×
Wiper: ✓

Navigation & sound

Navigation: ×
Navigation device: It is not
Audio: AM/FM radio with CS player
CD player: ×

Gear ratios

CVT	1	2	3	4	5	6	7	Rev	Main
—	2.071	1.242	0.828	—	—	—	—	—	1.657

Available colors

blackwhitegreen / Other greenMaroon (brown) / Other Maroon (brown)OliveNavy bluePurpleAshes / Other AshesYellowYellow-greenBlack (P)Magenta / Other MagentaSilver / Other SilverRed / Other RedBlue / Other BlueDark cyan / Other Dark cyanPearlGold / Other Gold
