JDM Vehicle Catalog

Vehicle Specs

CITROEN XSARA BREAK1.6

CITROEN XSARA

N7NFU · BREAK1.6

Description

Modification: BREAK1.6
Chassis ID: N7NFU
Dates releasing: 2004.2~
Base price, ¥: GH-N7NFU
Body size: 4370x1710x1420
Interior (LxWxH): 1810x1440x1150
Wheelbase: 2540
Track f/r: 1430mm/1440mm
Full weight, kg: 1200
Body type: Wagon
Doors / seats: 5 door / 5

Safe equipment

Driver's air bag: ✓
Front passenger air bag: ✓
Side airbags: ✓
ABS: ✓
TRC: ×
Belts w/ tensioner: ✓
Belts w/ effort limiter: ✓
Belts w/ holding: ✓
Child-seat fixation: ×
Safety planks: ✓
Brake assist: ✓
Energy-absorbing body: ×
EBD: ✓
Anti-theft device: ✓
Additional equipment: ×

Comfort

Air conditioner: Full Auto
Power window: ✓
Central switch: ✓
Steering column length: ✓
Steering column height: ✓
Cruise control: ✓
Leather steering wheel: ×
Leather seats: —
Power front seat: ×
Power rear seat: ×
Wood panel: ×
Sunroof: ◯
Alloy wheels: Option settings NO
Folding seat: split
Glass w/ UV filter: ×
Toned glasses: ×

Engine

Model: NFU
Type: water cooling inline 4 cylinder DOHC
Bore x stroke, mm: 78.5x82.0
Engine size, cc: 1587
Compression ratio: 11.0
Fuel injection: 電子制御燃料噴射装置
Max power, hp/rpm: 108ps(80kW)/5800rpm
Max torque, Nm/rpm: 15.0kg m(147N m)/4000rpm
Supercharger: ×
Fuel tank, liters: 54 l
Fuel: Unleaded premium gasoline
Fuel consumption, l/100km: 0

Steering & suspension

Steering: Power assist equipped rack&pinion
Front suspension: McPherson Strut
Rear suspension: トレーリングアーム
Front brake: Ventilated disk
Rear brake: disk
Front wheel: 195/55R15
Rear wheel: 195/55R15
Min turn diameter, m: ----

Gearbox

Number of stages: 4AT
Drive: FF
LSD: ----

Exterior equipment

Front fog lights: ✓
Rear fog lights: ✓
Xenon: ×
Extra front lights: ×
Spoilers (f / r): × / ×
Wiper: ✓

Navigation & sound

Navigation: ×
Navigation device: It is not
Audio: AM/FMラジオ
CD player: 単装

Gear ratios

CVT	1	2	3	4	5	6	7	Rev	Main
—	3.510	1.931	1.288	0.915	—	—	—	—	3.166

Available colors

black / Other blackwhite / Other whitegreen / Other greenMaroon (brown)Olive / Other OliveNavy blue / Other Navy bluePurpleAshes / Other AshesYellow / Other YellowYellow-green / Other Yellow-greenBlack (P) / Other Black (P)MagentaSilver / Other SilverRed / Other RedBlue / Other BlueDark cyanPearlGold
