JDM Vehicle Catalog

Vehicle Specs

DAIHATSU BOON 1.0CL

DAIHATSU BOON

M300S · 1.0CL

Description

Modification: 1.0CL
Chassis ID: M300S
Dates releasing: 2004.6~
Base price, ¥: DBA-M300S
Body size: 3595x1665x1535
Interior (LxWxH): 1830x1400x1275
Wheelbase: 2440
Track f/r: 1465mm/1475mm
Full weight, kg: 900
Body type: Hatch
Doors / seats: 5 door / 5

Safe equipment

Driver's air bag: ✓
Front passenger air bag: ✓
Side airbags: ◯
ABS: ✓
TRC: ×
Belts w/ tensioner: ✓
Belts w/ effort limiter: ✓
Belts w/ holding: ✓
Child-seat fixation: ✓
Safety planks: ×
Brake assist: ✓
Energy-absorbing body: 採用
EBD: ✓
Anti-theft device: ×
Additional equipment: ×

Comfort

Air conditioner: Manual
Power window: ✓
Central switch: ✓
Steering column length: ×
Steering column height: ✓
Cruise control: ×
Leather steering wheel: ×
Leather seats: —
Power front seat: ×
Power rear seat: ×
Wood panel: ×
Sunroof: ×
Alloy wheels: Option settings NO
Folding seat: split
Glass w/ UV filter: ✓
Toned glasses: ✓

Engine

Model: 1KR-FE
Type: water cooling inline 3 cylinder DOHC 12-valves
Bore x stroke, mm: 71.0x83.9
Engine size, cc: 996
Compression ratio: 10.5
Fuel injection: EFI
Max power, hp/rpm: 71ps(52kW)/6000rpm
Max torque, Nm/rpm: 9.6kg m(94N m)/3600rpm
Supercharger: ×
Fuel tank, liters: 40 l
Fuel: Regular unleaded gasoline
Fuel consumption, l/100km: 4.8

Steering & suspension

Steering: Power assist equipped rack&pinion
Front suspension: McPherson Strut type Coil spring
Rear suspension: Torsion beam
Front brake: Ventilated disk
Rear brake: Drum
Front wheel: 155/80R13 79S
Rear wheel: 155/80R13 79S
Min turn diameter, m: 4.3

Gearbox

Number of stages: 4AT
Drive: FF
LSD: ----

Exterior equipment

Front fog lights: ×
Rear fog lights: ◯
Xenon: ×
Extra front lights: ×
Spoilers (f / r): × / ×
Wiper: ✓

Navigation & sound

Navigation: ◯
Navigation device: CD
Audio: AM/FMラジオ
CD player: 単装

Gear ratios

CVT	1	2	3	4	5	6	7	Rev	Main
—	2.730	1.526	1.000	0.696	—	—	—	—	2.290

Available colors

blackwhitegreenMaroon (brown)OliveNavy blue / Dark blue mica metallicPurpleAshesYellowYellow-green / Other Yellow-greenBlack (P) / Other Black (P)Magenta / Other MagentaSilver / Bright silver metallicRed / Other RedBlueDark cyanPearl / Pearl white IGold / Champagne metallic opal
