DAIHATSU MAX RS

DAIHATSU MAX

L952S · RS

Description

Modification: RS
Chassis ID: L952S
Dates releasing: 2004.6~
Base price, ¥: ABA-L952S
Body size: 3395x1475x1550
Interior (LxWxH): 1765x1275x1270
Wheelbase: 2360
Track f/r: 1300mm/1290mm
Full weight, kg: 870
Body type: Key SUV
Doors / seats: 5 door / 4

Safe equipment

Driver's air bag: ✓
Front passenger air bag: ✓
Side airbags: ×
ABS: ✓
TRC: ×
Belts w/ tensioner: ✓
Belts w/ effort limiter: ✓
Belts w/ holding: ✓
Child-seat fixation: ✓
Safety planks: ✓
Brake assist: ✓
Energy-absorbing body: 採用
EBD: ✓
Anti-theft device: ×
Additional equipment: 衝撃感知安全システム

Comfort

Air conditioner: Manual
Power window: ✓
Central switch: ✓
Steering column length: ✓
Steering column height: ✓
Cruise control: ×
Leather steering wheel: ×
Leather seats: —
Power front seat: ×
Power rear seat: ×
Wood panel: ×
Sunroof: ×
Alloy wheels: 15 inches standard
Folding seat: split
Glass w/ UV filter: ✓
Toned glasses: ✓

Engine

Model: JB-DET
Type: inline 4 cylinder DOHC 16-valves IC-turbo
Bore x stroke, mm: 61.0x56.4
Engine size, cc: 659
Compression ratio: 8.2
Fuel injection: EFI
Max power, hp/rpm: 64ps(47kW)/6000rpm
Max torque, Nm/rpm: 10.2kg m(100N m)/3200rpm
Supercharger: IC turbo
Fuel tank, liters: 40 l
Fuel: Regular unleaded gasoline
Fuel consumption, l/100km: 6

Steering & suspension

Steering: Power assist equipped rack&pinion
Front suspension: McPherson Strut type
Rear suspension: Torsion beam
Front brake: Ventilated disk
Rear brake: Drum
Front wheel: 165/50R15 73V
Rear wheel: 165/50R15 73V
Min turn diameter, m: 4.7

Gearbox

Number of stages: 4AT
Drive: FF
LSD: ✓

Exterior equipment

Front fog lights: ✓
Rear fog lights: ×
Xenon: ✓
Extra front lights: ×
Spoilers (f / r): ✓ / ✓
Wiper: ✓

Navigation & sound

Navigation: ◯
Navigation device: HDD
Audio: It is not
CD player: ×

Gear ratios

CVT	1	2	3	4	5	6	7	Rev	Main
—	2.730	1.526	1.000	0.696	—	—	—	—	2.290

Available colors

black / black micawhitegreenMaroon (brown)OliveNavy bluePurpleAshesYellowYellow-green / Other Yellow-greenBlack (P) / Other Black (P)Magenta / Light rose-metallicSilver / Bright silver metallicRedBlueDark cyanPearl / Pearl white IGold / Champagne metallic opal
