DAIHATSU MAX XI

DAIHATSU MAX

L960S · XI

Description

Modification: XI
Chassis ID: L960S
Dates releasing: 2002.5~
Base price, ¥: LA-L960S
Body size: 3395x1475x1550
Interior (LxWxH): 1765x1275x1270
Wheelbase: 2360
Track f/r: 1300mm/1260mm
Full weight, kg: 860
Body type: Key SUV
Doors / seats: 5 door / 4

Safe equipment

Driver's air bag: ✓
Front passenger air bag: ✓
Side airbags: ×
ABS: ◯
TRC: ×
Belts w/ tensioner: ✓
Belts w/ effort limiter: ✓
Belts w/ holding: ✓
Child-seat fixation: ✓
Safety planks: ✓
Brake assist: ◯
Energy-absorbing body: 採用
EBD: ◯
Anti-theft device: ◯
Additional equipment: 衝撃感知安全システム

Comfort

Air conditioner: Manual
Power window: ✓
Central switch: ✓
Steering column length: ✓
Steering column height: ✓
Cruise control: ×
Leather steering wheel: ◯
Leather seats: —
Power front seat: ×
Power rear seat: ×
Wood panel: ◯
Sunroof: ×
Alloy wheels: 13 inches standard
Folding seat: split
Glass w/ UV filter: ✓
Toned glasses: ✓

Engine

Model: EF-VE
Type: inline 3 cylinder DOHC 12-valves
Bore x stroke, mm: 68.0x60.5
Engine size, cc: 659
Compression ratio: 10.5
Fuel injection: EFI
Max power, hp/rpm: 58ps(43kW)/7600rpm
Max torque, Nm/rpm: 6.2kg m(64N m)/4000rpm
Supercharger: ×
Fuel tank, liters: 37 l
Fuel: Regular unleaded gasoline
Fuel consumption, l/100km: 5.2

Steering & suspension

Steering: Power assist equipped rack&pinion
Front suspension: McPherson Strut type
Rear suspension: 3-link Coil spring
Front brake: disk
Rear brake: Drum
Front wheel: 155/65R13 73S
Rear wheel: 155/65R13 73S
Min turn diameter, m: 4.3

Gearbox

Number of stages: 5MT
Drive: Full-time 4WD
LSD: ----

Exterior equipment

Front fog lights: ✓
Rear fog lights: ×
Xenon: ×
Extra front lights: ×
Spoilers (f / r): ✓ / ◯
Wiper: ✓

Navigation & sound

Navigation: ×
Navigation device: It is not
Audio: AM/FM radio with MD player
CD player: 単装

Gear ratios

CVT	1	2	3	4	5	6	7	Rev	Main
—	—	—	—	—	—	—	—	—	----

Available colors

black / black micawhitegreenMaroon (brown)OliveNavy bluePurpleAshesYellow / Other YellowYellow-greenBlack (P) / Other Black (P)Magenta / Light rose-metallicSilverRedBlueDark cyanPearl / Pearl white IGold
