DAIHATSU STORIA CX

DAIHATSU STORIA

M101S · CX

Description

Modification: CX
Chassis ID: M101S
Dates releasing: 2003.4~
Base price, ¥: UA-M101S
Body size: 3690x1600x1450
Interior (LxWxH): 1745x1330x1165
Wheelbase: 2370
Track f/r: 1390mm/1375mm
Full weight, kg: 850
Body type: Hatch
Doors / seats: 5 door / 5

Safe equipment

Driver's air bag: ✓
Front passenger air bag: ✓
Side airbags: ◯
ABS: ✓
TRC: ×
Belts w/ tensioner: ✓
Belts w/ effort limiter: ✓
Belts w/ holding: ✓
Child-seat fixation: ✓
Safety planks: ✓
Brake assist: ✓
Energy-absorbing body: 採用
EBD: ✓
Anti-theft device: ×
Additional equipment: ×

Comfort

Air conditioner: Manual
Power window: ✓
Central switch: ✓
Steering column length: ×
Steering column height: ×
Cruise control: ×
Leather steering wheel: ×
Leather seats: —
Power front seat: ×
Power rear seat: ×
Wood panel: ✓
Sunroof: ×
Alloy wheels: Option settings YES
Folding seat: split
Glass w/ UV filter: ✓
Toned glasses: ◯

Engine

Model: K3-VE
Type: water cooling inline 4 cylinder DOHC 16-valves
Bore x stroke, mm: 72.0x79.7
Engine size, cc: 1297
Compression ratio: 10.0
Fuel injection: EFI
Max power, hp/rpm: 90ps(66kW)/6000rpm
Max torque, Nm/rpm: 12.6kg m(123N m)/4000rpm
Supercharger: ×
Fuel tank, liters: 40 l
Fuel: Regular unleaded gasoline
Fuel consumption, l/100km: 5

Steering & suspension

Steering: Power assist equipped rack&pinion
Front suspension: McPherson Strut type Coil spring
Rear suspension: Torsion beam
Front brake: Ventilated disk
Rear brake: Drum
Front wheel: 165/70R13 79S
Rear wheel: 165/70R13 79S
Min turn diameter, m: 4.3

Gearbox

Number of stages: 5MT
Drive: FF
LSD: ----

Exterior equipment

Front fog lights: ×
Rear fog lights: ×
Xenon: ×
Extra front lights: ×
Spoilers (f / r): × / ◯
Wiper: ✓

Navigation & sound

Navigation: ◯
Navigation device: CD
Audio: AM/FM radio with MD player
CD player: 単装

Gear ratios

CVT	1	2	3	4	5	6	7	Rev	Main
—	3.181	1.842	1.250	0.864	0.750	—	—	—	3.142

Available colors

blackwhitegreen / Other greenMaroon (brown)OliveNavy bluePurple / Other PurpleAshesYellowYellow-greenBlack (P)Magenta / Light rose-metallicSilver / Bright silver metallicRedBlueDark cyanPearl / Pearl white IGold / Champagne metallic opal
