EUROPE FORD MONDEO SEDAN LX

EUROPE FORD MONDEO

WF0FRF · SEDAN LX

Description

Modification: SEDAN LX
Chassis ID: WF0FRF
Dates releasing: 1996.11~
Base price, ¥: KD-WF0FRF
Body size: 4560x1750x1435
Interior (LxWxH): 1815x1320x1165
Wheelbase: 2700
Track f/r: 1500mm/1485mm
Full weight, kg: 1320
Body type: Sedan
Doors / seats: 4 door / 5

Safe equipment

Driver's air bag: ✓
Front passenger air bag: ✓
Side airbags: ×
ABS: ✓
TRC: ×
Belts w/ tensioner: ✓
Belts w/ effort limiter: ×
Belts w/ holding: ✓
Child-seat fixation: ×
Safety planks: ✓
Brake assist: ×
Energy-absorbing body: ×
EBD: ×
Anti-theft device: ×
Additional equipment: ×

Comfort

Air conditioner: Manual
Power window: ✓
Central switch: ✓
Steering column length: ✓
Steering column height: ✓
Cruise control: ×
Leather steering wheel: ×
Leather seats: —
Power front seat: ×
Power rear seat: ×
Wood panel: ×
Sunroof: ×
Alloy wheels: Option settings NO
Folding seat: split
Glass w/ UV filter: ×
Toned glasses: ×

Engine

Model: ----
Type: water cooling inline 4 cylinder OHCturbo (Diesel)
Bore x stroke, mm: 82.5x82.0
Engine size, cc: 1753
Compression ratio: 21.5
Fuel injection: 電子制御フュエルインジェクション
Max power, hp/rpm: 90ps(----kW)/4500rpm
Max torque, Nm/rpm: 18.1kg m(----N m)/2000rpm
Supercharger: Turbo
Fuel tank, liters: 61 l
Fuel: Diesel
Fuel consumption, l/100km: 0

Steering & suspension

Steering: Power assist equipped rack&pinion
Front suspension: McPherson Strut
Rear suspension: クワドラリンク
Front brake: Ventilated disk
Rear brake: Drum
Front wheel: 185/65R14
Rear wheel: 185/65R14
Min turn diameter, m: 5.5

Gearbox

Number of stages: 5MT
Drive: FF
LSD: ----

Exterior equipment

Front fog lights: ×
Rear fog lights: ✓
Xenon: ×
Extra front lights: ×
Spoilers (f / r): × / ×
Wiper: ×

Navigation & sound

Navigation: ×
Navigation device: It is not
Audio: AM/FM radio with CS player
CD player: ×

Gear ratios

CVT	1	2	3	4	5	6	7	Rev	Main
—	3.666	2.047	1.258	0.864	0.674	—	—	—	3.460

Available colors

blackwhite / Other whitegreen / Other greenMaroon (brown)OliveNavy blue / Other Navy bluePurpleAshesYellowYellow-greenBlack (P)MagentaSilver / Other SilverRed / Other RedBlueDark cyanPearlGold
