EUROPE FORD MONDEO WAGON GHIA

EUROPE FORD MONDEO

WF0CJB · WAGON GHIA

Description

Modification: WAGON GHIA
Chassis ID: WF0CJB
Dates releasing: 2002.5~
Base price, ¥: GH-WF0CJB
Body size: 4805x1810x1470
Interior (LxWxH): 1915x1445x1210
Wheelbase: 2755
Track f/r: 1525mm/1540mm
Full weight, kg: 1470
Body type: Wagon
Doors / seats: 5 door / 5

Safe equipment

Driver's air bag: ✓
Front passenger air bag: ✓
Side airbags: ✓
ABS: ✓
TRC: ×
Belts w/ tensioner: ✓
Belts w/ effort limiter: ✓
Belts w/ holding: ✓
Child-seat fixation: ×
Safety planks: ✓
Brake assist: ✓
Energy-absorbing body: ×
EBD: ✓
Anti-theft device: ✓
Additional equipment: ×

Comfort

Air conditioner: Full Auto
Power window: ✓
Central switch: ✓
Steering column length: ✓
Steering column height: ✓
Cruise control: ◯
Leather steering wheel: ✓
Leather seats: —
Power front seat: ✓
Power rear seat: ×
Wood panel: ✓
Sunroof: ×
Alloy wheels: 16 inches standard
Folding seat: split
Glass w/ UV filter: ×
Toned glasses: ×

Engine

Model: ----
Type: water cooling inline 4 cylinder DOHC
Bore x stroke, mm: 87.5x83.1
Engine size, cc: 1998
Compression ratio: 10.8
Fuel injection: 電子制御フュエルインジェクション
Max power, hp/rpm: 145ps(107kW)/6000rpm
Max torque, Nm/rpm: 19.4kg m(190N m)/4500rpm
Supercharger: ×
Fuel tank, liters: 58 l
Fuel: Unleaded premium gasoline
Fuel consumption, l/100km: 10.5

Steering & suspension

Steering: Power assist equipped rack&pinion
Front suspension: McPherson Strut type
Rear suspension: ショート&ロングアーム
Front brake: Ventilated disk
Rear brake: disk
Front wheel: 205/55R16
Rear wheel: 205/55R16
Min turn diameter, m: 5.8

Gearbox

Number of stages: 4AT
Drive: FF
LSD: ----

Exterior equipment

Front fog lights: ✓
Rear fog lights: ✓
Xenon: ×
Extra front lights: ×
Spoilers (f / r): ◯ / ◯
Wiper: ✓

Navigation & sound

Navigation: ◯
Navigation device: DVD
Audio: AM/FMラジオ
CD player: 連装

Gear ratios

CVT	1	2	3	4	5	6	7	Rev	Main
—	2.890	1.571	1.000	0.698	—	—	—	—	2.310

Available colors

blackwhitegreenMaroon (brown)OliveNavy blue / Other Navy bluePurpleAshesYellowYellow-greenBlack (P)MagentaSilver / Other SilverRed / Other RedBlueDark cyanPearlGold
