EUROPE FORD MONDEO WAGON GHIA X

EUROPE FORD MONDEO

WF0LCB · WAGON GHIA X

Description

Modification: WAGON GHIA X
Chassis ID: WF0LCB
Dates releasing: 2005.11~
Base price, ¥: GH-WF0LCB
Body size: 4805x1810x1470
Interior (LxWxH): 1915x1445x1210
Wheelbase: 2755
Track f/r: 1525mm/1540mm
Full weight, kg: 1560
Body type: Wagon
Doors / seats: 5 door / 5

Safe equipment

Driver's air bag: ✓
Front passenger air bag: ✓
Side airbags: ✓
ABS: ✓
TRC: ×
Belts w/ tensioner: ✓
Belts w/ effort limiter: ✓
Belts w/ holding: ✓
Child-seat fixation: ×
Safety planks: ✓
Brake assist: ✓
Energy-absorbing body: ×
EBD: ✓
Anti-theft device: ✓
Additional equipment: ESP(エレクトロニックスタビリティ PRO グラム)

Comfort

Air conditioner: Full Auto
Power window: ✓
Central switch: ✓
Steering column length: ✓
Steering column height: ✓
Cruise control: ×
Leather steering wheel: ×
Leather seats: —
Power front seat: ✓
Power rear seat: ×
Wood panel: ✓
Sunroof: ×
Alloy wheels: 17 inches standard
Folding seat: split
Glass w/ UV filter: ×
Toned glasses: ×

Engine

Model: ----
Type: water cooling V-type 6 cylinder DOHC
Bore x stroke, mm: 81.6x79.5
Engine size, cc: 2494
Compression ratio: 9.8
Fuel injection: 電子制御フュエルインジェクション
Max power, hp/rpm: 170ps(125kW)/6000rpm
Max torque, Nm/rpm: 22.4kg m(220N m)/4250rpm
Supercharger: ×
Fuel tank, liters: 58 l
Fuel: Unleaded premium gasoline
Fuel consumption, l/100km: 11.3

Steering & suspension

Steering: Power assist equipped rack&pinion
Front suspension: McPherson Strut type
Rear suspension: ショート&ロングアーム
Front brake: Ventilated disk
Rear brake: disk
Front wheel: 205/50R17
Rear wheel: 205/50R17
Min turn diameter, m: 5.8

Gearbox

Number of stages: 5AT
Drive: FF
LSD: ----

Exterior equipment

Front fog lights: ✓
Rear fog lights: ✓
Xenon: ✓
Extra front lights: ×
Spoilers (f / r): × / ×
Wiper: ✓

Navigation & sound

Navigation: ×
Navigation device: It is not
Audio: AM/FMラジオ
CD player: 連装

Gear ratios

CVT	1	2	3	4	5	6	7	Rev	Main
—	3.801	2.131	1.364	0.935	0.685	—	—	—	2.970

Available colors

black / Other blackwhitegreenMaroon (brown)OliveNavy bluePurpleAshesYellowYellow-greenBlack (P)MagentaSilver / Other SilverRed / Other RedBlueDark cyanPearlGold
