FIAT COUPE FIAT BASEGRADE

FIAT COUPE FIAT

175A3 · BASEGRADE

Description

Modification: BASEGRADE
Chassis ID: 175A3
Dates releasing: 1999.1~
Base price, ¥: E-175A3
Body size: 4250x1765x1355
Interior (LxWxH): ----x----x----
Wheelbase: 2540
Track f/r: 1490mm/1475mm
Full weight, kg: 1330
Body type: Coupe
Doors / seats: 2 door / 4

Safe equipment

Driver's air bag: ✓
Front passenger air bag: ✓
Side airbags: ×
ABS: ✓
TRC: ×
Belts w/ tensioner: ✓
Belts w/ effort limiter: ×
Belts w/ holding: ✓
Child-seat fixation: ×
Safety planks: ×
Brake assist: ×
Energy-absorbing body: ×
EBD: ×
Anti-theft device: ×
Additional equipment: FPS(緊急時燃料遮断装置)

Comfort

Air conditioner: Full Auto
Power window: ✓
Central switch: ✓
Steering column length: ×
Steering column height: ✓
Cruise control: ×
Leather steering wheel: ✓
Leather seats: —
Power front seat: ×
Power rear seat: ×
Wood panel: ×
Sunroof: ×
Alloy wheels: 16 inches standard
Folding seat: split
Glass w/ UV filter: ×
Toned glasses: ✓

Engine

Model: ----
Type: inline 5 cylinder DOHC 20-valves IC-turbo
Bore x stroke, mm: 82.0x75.6
Engine size, cc: 1996
Compression ratio: 8.5
Fuel injection: ボッシュモトロニック電子制御 type 燃&
Max power, hp/rpm: 220ps(162kW)/5750rpm
Max torque, Nm/rpm: 31.0kg m(304.0N m)/2500rpm
Supercharger: IC turbo
Fuel tank, liters: 63 l
Fuel: Unleaded premium gasoline
Fuel consumption, l/100km: 0

Steering & suspension

Steering: Power assist equipped rack&pinion
Front suspension: McPherson Strut
Rear suspension: トレーリングアーム
Front brake: Ventilated disk
Rear brake: disk
Front wheel: 205/50ZR16
Rear wheel: 205/50ZR16
Min turn diameter, m: ----

Gearbox

Number of stages: 5MT
Drive: FF
LSD: ----

Exterior equipment

Front fog lights: ✓
Rear fog lights: ✓
Xenon: ×
Extra front lights: ×
Spoilers (f / r): × / ×
Wiper: ✓

Navigation & sound

Navigation: ×
Navigation device: It is not
Audio: AM/FM radio with CS player
CD player: ×

Gear ratios

CVT	1	2	3	4	5	6	7	Rev	Main
—	3.800	2.235	1.520	1.156	0.914	—	—	—	3.545

Available colors

black / Other blackwhitegreenMaroon (brown)OliveNavy bluePurpleAshesYellow / Other YellowYellow-greenBlack (P)MagentaSilver / Other SilverRed / Other RedBlue / Other BlueDark cyanPearlGold
