HONDA CIVIC HYBRID BASE GRADE

HONDA CIVIC HYBRID

ES9 · BASE GRADE

Description

Modification: BASE GRADE
Chassis ID: ES9
Dates releasing: 2004.4~
Base price, ¥: CAA-ES9
Body size: 4470x1695x1430
Interior (LxWxH): 1865x1380x1170
Wheelbase: 2620
Track f/r: 1470mm/1470mm
Full weight, kg: 1200
Body type: Sedan
Doors / seats: 4 door / 5

Safe equipment

Driver's air bag: ✓
Front passenger air bag: ✓
Side airbags: ◯
ABS: ✓
TRC: ×
Belts w/ tensioner: ✓
Belts w/ effort limiter: ✓
Belts w/ holding: ✓
Child-seat fixation: ✓
Safety planks: ✓
Brake assist: ✓
Energy-absorbing body: 採用
EBD: ✓
Anti-theft device: ✓
Additional equipment: ×

Comfort

Air conditioner: Full Auto
Power window: ✓
Central switch: ✓
Steering column length: ×
Steering column height: ✓
Cruise control: ×
Leather steering wheel: ✓
Leather seats: —
Power front seat: ×
Power rear seat: ×
Wood panel: ✓
Sunroof: ◯
Alloy wheels: 14 inches standard
Folding seat: ×
Glass w/ UV filter: ✓
Toned glasses: ✓

Engine

Model: LDA
Type: water cooling inline 4 cylinder SOHC 8-valves +
Bore x stroke, mm: 73.0x80.0
Engine size, cc: 1339
Compression ratio: 10.8
Fuel injection: 電子制御燃料噴射 type ( HONDA PGM-FI)
Max power, hp/rpm: 86ps(63kW)/5700rpm
Max torque, Nm/rpm: 12.1kg m(119N m)/3300rpm
Supercharger: ×
Fuel tank, liters: 50 l
Fuel: Regular unleaded gasoline
Fuel consumption, l/100km: 3.4

Steering & suspension

Steering: Power assist equipped rack&pinion
Front suspension: McPherson
Rear suspension: Double wishbone
Front brake: Ventilated disk
Rear brake: Drum
Front wheel: 185/70R14 88S
Rear wheel: 185/70R14 88S
Min turn diameter, m: 5.3

Gearbox

Number of stages: CVT
Drive: FF
LSD: ----

Exterior equipment

Front fog lights: ✓
Rear fog lights: ×
Xenon: ◯
Extra front lights: ×
Spoilers (f / r): × / ✓
Wiper: ×

Navigation & sound

Navigation: ◯
Navigation device: DVD
Audio: AM/FMラジオ
CD player: 単装

Gear ratios

CVT	1	2	3	4	5	6	7	Rev	Main
2.367~0.407	—	—	—	—	—	—	—	—	4.226~3.214

Available colors

black / Nighthawk Black PearlwhitegreenMaroon (brown)OliveNavy bluePurpleAshes / Other AshesYellowYellow-greenBlack (P) / Other Black (P)MagentaSilver / Satin Silver MetallicRed / Other RedBlue / Other BlueDark cyanPearl / Other PearlGold / Other Gold
