HONDA HRV J4 SPECIAL

HONDA HRV

GH2 · J4 SPECIAL

Description

Modification: J4 SPECIAL
Chassis ID: GH2
Dates releasing: 2001.12~
Base price, ¥: LA-GH2
Body size: 3995x1695x1575
Interior (LxWxH): 1705x1365x1195
Wheelbase: 2360
Track f/r: 1470mm/1455mm
Full weight, kg: 1200
Body type: SUV
Doors / seats: 3 door / 5

Safe equipment

Driver's air bag: ✓
Front passenger air bag: ✓
Side airbags: ×
ABS: ✓
TRC: ×
Belts w/ tensioner: ✓
Belts w/ effort limiter: ✓
Belts w/ holding: ✓
Child-seat fixation: ✓
Safety planks: ✓
Brake assist: ✓
Energy-absorbing body: 採用
EBD: ✓
Anti-theft device: ×
Additional equipment: ×

Comfort

Air conditioner: Manual
Power window: ✓
Central switch: ✓
Steering column length: ×
Steering column height: ✓
Cruise control: ×
Leather steering wheel: ×
Leather seats: —
Power front seat: ×
Power rear seat: ×
Wood panel: ×
Sunroof: ◯
Alloy wheels: Option settings YES
Folding seat: split
Glass w/ UV filter: ✓
Toned glasses: ✓

Engine

Model: D16A
Type: water cooling inline 4 cylinder SOHC 16-valves
Bore x stroke, mm: 75.0x90.0
Engine size, cc: 1590
Compression ratio: 9.6
Fuel injection: 電子制御燃料噴射 type ( HONDA PGM-FI)
Max power, hp/rpm: 105ps(77kW)/6200rpm
Max torque, Nm/rpm: 14.1kg m(138N m)/3400rpm
Supercharger: ×
Fuel tank, liters: 55 l
Fuel: Regular unleaded gasoline
Fuel consumption, l/100km: 7.3

Steering & suspension

Steering: Power assist equipped rack&pinion
Front suspension: McPherson
Rear suspension: ドディオン
Front brake: disk
Rear brake: Drum
Front wheel: 195/70R15 92S
Rear wheel: 195/70R15 92S
Min turn diameter, m: 5.0

Gearbox

Number of stages: CVT
Drive: Full-time 4WD
LSD: ----

Exterior equipment

Front fog lights: ×
Rear fog lights: ×
Xenon: ×
Extra front lights: ×
Spoilers (f / r): ✓ / ◯
Wiper: ✓

Navigation & sound

Navigation: ◯
Navigation device: It is not
Audio: AM/FMラジオ
CD player: 単装

Gear ratios

CVT	1	2	3	4	5	6	7	Rev	Main
2.466~0.449	—	—	—	—	—	—	—	—	2.466

Available colors

black / Nighthawk Black Pearlwhite / Taffeta Whitegreen / Other greenMaroon (brown)OliveNavy bluePurpleAshesYellowYellow-greenBlack (P)MagentaSilver / Satin Silver MetallicRed / Milano RedBlue / Other BlueDark cyanPearl / Other PearlGold / Other Gold
