HONDA INTEGRA TYPE R

HONDA INTEGRA

DC5 · TYPE R

Description

Modification: TYPE R
Chassis ID: DC5
Dates releasing: 2004.3~
Base price, ¥: ABA-DC5
Body size: 4385x1725x1385
Interior (LxWxH): 1770x1430x1135
Wheelbase: 2570
Track f/r: 1490mm/1490mm
Full weight, kg: 1180
Body type: Coupe
Doors / seats: 3 door / 4

Safe equipment

Driver's air bag: ✓
Front passenger air bag: ✓
Side airbags: ×
ABS: ✓
TRC: ×
Belts w/ tensioner: ✓
Belts w/ effort limiter: ✓
Belts w/ holding: ✓
Child-seat fixation: ✓
Safety planks: ✓
Brake assist: ×
Energy-absorbing body: 採用
EBD: ×
Anti-theft device: ×
Additional equipment: ×

Comfort

Air conditioner: Full Auto
Power window: ✓
Central switch: ✓
Steering column length: ×
Steering column height: ✓
Cruise control: ×
Leather steering wheel: ✓
Leather seats: —
Power front seat: ×
Power rear seat: ×
Wood panel: ×
Sunroof: ×
Alloy wheels: 17 inches standard
Folding seat: split
Glass w/ UV filter: ✓
Toned glasses: ◯

Engine

Model: K20A
Type: water cooling inline 4 cylinder DOHC 16-valves
Bore x stroke, mm: 86.0x86.0
Engine size, cc: 1998
Compression ratio: 11.5
Fuel injection: 電子制御燃料噴射 type ( HONDA PGM-FI)
Max power, hp/rpm: 220ps(162kW)/8000rpm
Max torque, Nm/rpm: 21.0kg m(206N m)/7000rpm
Supercharger: ×
Fuel tank, liters: 50 l
Fuel: Unleaded premium gasoline
Fuel consumption, l/100km: 8.1

Steering & suspension

Steering: Power assist equipped rack&pinion
Front suspension: McPherson
Rear suspension: Double wishbone
Front brake: disk
Rear brake: disk
Front wheel: 215/45Z R17
Rear wheel: 215/45Z R17
Min turn diameter, m: 5.7

Gearbox

Number of stages: 6MT
Drive: FF
LSD: ✓

Exterior equipment

Front fog lights: ×
Rear fog lights: ×
Xenon: ✓
Extra front lights: ×
Spoilers (f / r): ✓ / ✓
Wiper: ◯

Navigation & sound

Navigation: ×
Navigation device: It is not
Audio: It is not
CD player: ×

Gear ratios

CVT	1	2	3	4	5	6	7	Rev	Main
—	3.266	2.130	1.517	1.212	0.972	0.780	—	—	3.583

Available colors

black / Other blackwhite / Other whitegreenMaroon (brown)OliveNavy bluePurpleAshesYellowYellow-greenBlack (P)MagentaSilver / Other SilverRed / Milano RedBlue / Other BlueDark cyanPearlGold
