HONDA Z TURBO

HONDA Z

PA1 · TURBO

Description

Modification: TURBO
Chassis ID: PA1
Dates releasing: 2000.6~
Base price, ¥: GF-PA1
Body size: 3395x1475x1675
Interior (LxWxH): 1665x1220x1135
Wheelbase: 2360
Track f/r: 1280mm/1290mm
Full weight, kg: 970
Body type: Key SUV
Doors / seats: 3 door / 4

Safe equipment

Driver's air bag: ✓
Front passenger air bag: ✓
Side airbags: ×
ABS: ◯
TRC: ×
Belts w/ tensioner: ✓
Belts w/ effort limiter: ✓
Belts w/ holding: ✓
Child-seat fixation: ✓
Safety planks: ✓
Brake assist: ◯
Energy-absorbing body: 採用
EBD: ×
Anti-theft device: ×
Additional equipment: ×

Comfort

Air conditioner: Manual
Power window: ✓
Central switch: ✓
Steering column length: ×
Steering column height: ×
Cruise control: ×
Leather steering wheel: ×
Leather seats: —
Power front seat: ×
Power rear seat: ×
Wood panel: ◯
Sunroof: ×
Alloy wheels: Option settings YES
Folding seat: split
Glass w/ UV filter: ✓
Toned glasses: ◯

Engine

Model: E07Z
Type: water cooling inline 3 cylinder SOHC 12-valves IC-turbo
Bore x stroke, mm: 66.0x64.0
Engine size, cc: 656
Compression ratio: 8.5
Fuel injection: 電子制御燃料噴射 type ( HONDA PGM-FI)
Max power, hp/rpm: 64ps(47kW)/6000rpm
Max torque, Nm/rpm: 9.5kg m(93N m)/3700rpm
Supercharger: IC turbo
Fuel tank, liters: 35 l
Fuel: Regular unleaded gasoline
Fuel consumption, l/100km: 6.4

Steering & suspension

Steering: Power assist equipped rack&pinion
Front suspension: McPherson
Rear suspension: ドディオン
Front brake: disk
Rear brake: Drum
Front wheel: 175/80R15 90Q
Rear wheel: 175/80R15 90Q
Min turn diameter, m: 4.6

Gearbox

Number of stages: 4AT
Drive: Full-time 4WD
LSD: ◯

Exterior equipment

Front fog lights: ◯
Rear fog lights: ×
Xenon: ×
Extra front lights: ×
Spoilers (f / r): ◯ / ◯
Wiper: ✓

Navigation & sound

Navigation: ◯
Navigation device: It is not
Audio: AM/FM radio with CS player
CD player: ×

Gear ratios

CVT	1	2	3	4	5	6	7	Rev	Main
—	2.722	1.551	1.027	0.744	—	—	—	—	1.954

Available colors

black / Nighthawk Black Pearlwhite / Taffeta WhitegreenMaroon (brown)OliveNavy bluePurpleAshesYellowYellow-greenBlack (P)MagentaSilver / Other SilverRed / Other RedBlue / Other BlueDark cyan / Other Dark cyanPearlGold
