Vehicle Specs

HYUNDAI ELANTRA 2.0GLS

HYUNDAI ELANTRA

XD20 · 2.0GLS

Description

Modification: 2.0GLS
Chassis ID: XD20
Dates releasing: 2002.8~
Base price, ¥: GH-XD20
Body size: 4510x1720x1425
Interior (LxWxH): 1915x1440x1180
Wheelbase: 2610
Track f/r: 1485mm/1475mm
Full weight, kg: 1290
Body type: Sedan
Doors / seats: 4 door / 5

Safe equipment

Driver's air bag: ✓
Front passenger air bag: ✓
Side airbags: ✓
ABS: ✓
TRC: ◯
Belts w/ tensioner: ✓
Belts w/ effort limiter: ✓
Belts w/ holding: ✓
Child-seat fixation: ×
Safety planks: ✓
Brake assist: ×
Energy-absorbing body: ×
EBD: ✓
Anti-theft device: ×
Additional equipment: ×

Comfort

Air conditioner: Manual
Power window: ✓
Central switch: ✓
Steering column length: ×
Steering column height: ✓
Cruise control: ×
Leather steering wheel: ✓
Leather seats: —
Power front seat: ×
Power rear seat: ×
Wood panel: ✓
Sunroof: ◯
Alloy wheels: Option settings NO
Folding seat: split
Glass w/ UV filter: ×
Toned glasses: ×

Engine

Model: G4GC
Type: inline 4 cylinder DOHC 16-valves
Bore x stroke, mm: 82.0x93.5
Engine size, cc: 1975
Compression ratio: 10.1
Fuel injection: Electronically controlled fuel injection system
Max power, hp/rpm: 137ps(101kW)/6000rpm
Max torque, Nm/rpm: 18.2kg m(178N m)/4500rpm
Supercharger: ×
Fuel tank, liters: 55 l
Fuel: Regular unleaded gasoline
Fuel consumption, l/100km: 8.5

Steering & suspension

Steering: Power assist equipped rack&pinion
Front suspension: McPherson
Rear suspension: デュアルリンク
Front brake: Ventilated disk
Rear brake: disk
Front wheel: 185/65R15
Rear wheel: 185/65R15
Min turn diameter, m: 5.1

Gearbox

Number of stages: 4AT
Drive: FF
LSD: ----

Exterior equipment

Front fog lights: ✓
Rear fog lights: ×
Xenon: ×
Extra front lights: ×
Spoilers (f / r): × / ×
Wiper: ×

Navigation & sound

Navigation: ×
Navigation device: It is not
Audio: It is not
CD player: ×

Gear ratios

CVT	1	2	3	4	5	6	7	Rev	Main
—	2.842	1.529	1.000	0.712	—	—	—	—	2.480

Available colors

black / Other blackwhite / Other whitegreenMaroon (brown)OliveNavy bluePurpleAshesYellowYellow-greenBlack (P)MagentaSilver / Other SilverRed / Other RedBlueDark cyan / Other Dark cyanPearlGold
