HYUNDAI SONATA 2.4GLS

HYUNDAI SONATA

NF24 · 2.4GLS

Description

Modification: 2.4GLS
Chassis ID: NF24
Dates releasing: 2005.9~
Base price, ¥: GH-NF24
Body size: 4800x1830x1475
Interior (LxWxH): 1975x1525x1225
Wheelbase: 2730
Track f/r: 1565mm/1550mm
Full weight, kg: 1490
Body type: Sedan
Doors / seats: 4 door / 5

Safe equipment

Driver's air bag: ✓
Front passenger air bag: ✓
Side airbags: ✓
ABS: ✓
TRC: ×
Belts w/ tensioner: ✓
Belts w/ effort limiter: ✓
Belts w/ holding: ✓
Child-seat fixation: ×
Safety planks: ✓
Brake assist: ×
Energy-absorbing body: ×
EBD: ✓
Anti-theft device: ✓
Additional equipment: ESP(エレクトロニックスタビリティ PRO グラム)

Comfort

Air conditioner: Full Auto
Power window: ✓
Central switch: ✓
Steering column length: ✓
Steering column height: ✓
Cruise control: ×
Leather steering wheel: ✓
Leather seats: —
Power front seat: ✓
Power rear seat: ×
Wood panel: ✓
Sunroof: ×
Alloy wheels: 16 inches standard
Folding seat: split
Glass w/ UV filter: ✓
Toned glasses: ×

Engine

Model: G4KC
Type: inline 4 cylinder DOHC 16-valves
Bore x stroke, mm: 88.0x97.0
Engine size, cc: 2359
Compression ratio: 10.5
Fuel injection: Electronically controlled fuel injection system
Max power, hp/rpm: 164ps(121kW)/5800rpm
Max torque, Nm/rpm: 23.1kg m(227N m)/4250rpm
Supercharger: ×
Fuel tank, liters: 70 l
Fuel: Regular unleaded gasoline
Fuel consumption, l/100km: 0

Steering & suspension

Steering: Power assist equipped rack&pinion
Front suspension: Double wishbone
Rear suspension: Multi-link
Front brake: Ventilated disk
Rear brake: disk
Front wheel: 215/60R16
Rear wheel: 215/60R16
Min turn diameter, m: 5.46

Gearbox

Number of stages: 4AT
Drive: FF
LSD: ----

Exterior equipment

Front fog lights: ✓
Rear fog lights: ✓
Xenon: ×
Extra front lights: ✓
Spoilers (f / r): × / ×
Wiper: ×

Navigation & sound

Navigation: ×
Navigation device: It is not
Audio: AM/FM radio with CS player
CD player: 連装

Gear ratios

CVT	1	2	3	4	5	6	7	Rev	Main
—	2.842	1.529	1.000	0.712	—	—	—	—	2.480

Available colors

black / Other blackwhite / Other whitegreenMaroon (brown)OliveNavy bluePurpleAshesYellowYellow-greenBlack (P)MagentaSilver / Other SilverRedBlue / Other BlueDark cyanPearl / Other PearlGold
