ISUZU FARGO WAGON LS

ISUZU FARGO WAGON

JARME24 · LS

Description

Modification: LS
Chassis ID: JARME24
Dates releasing: 1995.8~
Base price, ¥: KD-JARME24
Body size: 4525x1725x1990
Interior (LxWxH): 3280x1535x1305
Wheelbase: 2375
Track f/r: 1475mm/1425mm
Full weight, kg: 2100
Body type: MV 1Box
Doors / seats: 4 door / 8

Safe equipment

Driver's air bag: ✓
Front passenger air bag: ×
Side airbags: ×
ABS: ×
TRC: ×
Belts w/ tensioner: ×
Belts w/ effort limiter: ×
Belts w/ holding: ✓
Child-seat fixation: ×
Safety planks: ×
Brake assist: ×
Energy-absorbing body: ×
EBD: ×
Anti-theft device: ×
Additional equipment: ×

Comfort

Air conditioner: Dual air conditioning
Power window: ✓
Central switch: ✓
Steering column length: ×
Steering column height: ✓
Cruise control: ×
Leather steering wheel: ×
Leather seats: —
Power front seat: ×
Power rear seat: ×
Wood panel: ×
Sunroof: ツイン
Alloy wheels: Option settings YES
Folding seat: split
Glass w/ UV filter: ×
Toned glasses: ✓

Engine

Model: TD27ETI
Type: water cooling inline 4 cylinder OHVIC-turbo (Diesel)
Bore x stroke, mm: 96.0x92.0
Engine size, cc: 2663
Compression ratio: 22.3
Fuel injection: EDI電子制御燃料噴射装置
Max power, hp/rpm: 130ps(96kW)/4000rpm
Max torque, Nm/rpm: 28.4kg m(278.5N m)/2000rpm
Supercharger: IC turbo
Fuel tank, liters: 60 l
Fuel: Diesel
Fuel consumption, l/100km: 0

Steering & suspension

Steering: Other
Front suspension: Double wishbone
Rear suspension: リジットリーフ
Front brake: Ventilated disk
Rear brake: Drum
Front wheel: 215/70R15 98S
Rear wheel: 215/70R15 98S
Min turn diameter, m: 5.0

Gearbox

Number of stages: 4AT
Drive: Part-time 4WD
LSD: ----

Exterior equipment

Front fog lights: ✓
Rear fog lights: ×
Xenon: ×
Extra front lights: ×
Spoilers (f / r): × / ◯
Wiper: ✓

Navigation & sound

Navigation: ×
Navigation device: It is not
Audio: AM/FM radio with CS player
CD player: ×

Gear ratios

CVT	1	2	3	4	5	6	7	Rev	Main
—	2.785	1.545	1.000	0.694	—	—	—	—	2.272

Available colors

black / Other blackwhitegreen / Other greenMaroon (brown)OliveNavy blue / Other Navy bluePurpleAshesYellowYellow-greenBlack (P)MagentaSilverRedBlueDark cyanPearlGold
