JAGUAR STYPE 4.2 V8

JAGUAR STYPE

J01HC · 4.2 V8

Description

Modification: 4.2 V8
Chassis ID: J01HC
Dates releasing: 2002.9~
Base price, ¥: GH-J01HC
Body size: 4880x1820x1445
Interior (LxWxH): ----x----x----
Wheelbase: 2910
Track f/r: 1540mm/1545mm
Full weight, kg: 1760
Body type: Sedan
Doors / seats: 4 door / 5

Safe equipment

Driver's air bag: ✓
Front passenger air bag: ✓
Side airbags: ✓
ABS: ✓
TRC: ✓
Belts w/ tensioner: ✓
Belts w/ effort limiter: ×
Belts w/ holding: ✓
Child-seat fixation: ×
Safety planks: ✓
Brake assist: ✓
Energy-absorbing body: ×
EBD: ×
Anti-theft device: ✓
Additional equipment: A.R.T.S.(コンピュータ制御包括的乗員安全システム) ダイナミックスタビリテ&#1

Comfort

Air conditioner: Full Auto
Power window: ✓
Central switch: ✓
Steering column length: ✓
Steering column height: ✓
Cruise control: ✓
Leather steering wheel: ×
Leather seats: —
Power front seat: ✓
Power rear seat: ×
Wood panel: ✓
Sunroof: ◯
Alloy wheels: 17 inches standard
Folding seat: split
Glass w/ UV filter: ×
Toned glasses: ×

Engine

Model: H8
Type: water cooling V-type 8 cylinder DOHC
Bore x stroke, mm: 86.0x90.3
Engine size, cc: 4196
Compression ratio: 11.0
Fuel injection: 電子制御燃料噴射
Max power, hp/rpm: 304ps(224kW)/6000rpm
Max torque, Nm/rpm: 42.9kg m(421N m)/4100rpm
Supercharger: ×
Fuel tank, liters: 69 l
Fuel: Unleaded premium gasoline
Fuel consumption, l/100km: 13.3

Steering & suspension

Steering: Power assist equipped rack&pinion
Front suspension: Double wishbone
Rear suspension: Double wishbone
Front brake: Ventilated disk
Rear brake: Ventilated disk
Front wheel: 235/50ZR17
Rear wheel: 235/50ZR17
Min turn diameter, m: 5.4

Gearbox

Number of stages: 6AT
Drive: FR
LSD: ----

Exterior equipment

Front fog lights: ✓
Rear fog lights: ✓
Xenon: ◯
Extra front lights: ×
Spoilers (f / r): × / ×
Wiper: ×

Navigation & sound

Navigation: ✓
Navigation device: DVD
Audio: AM/FM radio with CS player
CD player: 連装

Gear ratios

CVT	1	2	3	4	5	6	7	Rev	Main
—	—	—	—	—	—	—	—	—	----

Available colors

black / Other blackwhite / Other whitegreen / Other greenMaroon (brown) / Other Maroon (brown)OliveNavy blue / Other Navy bluePurpleAshes / Other AshesYellowYellow-greenBlack (P) / Other Black (P)MagentaSilver / Other SilverRedBlue / Other BlueDark cyanPearlGold / Other Gold
