JDM Vehicle Catalog

Vehicle Specs

MAZDA MILLENIA MC

MAZDA MILLENIA

TA3A · MC

Description

Modification: MC
Chassis ID: TA3A
Dates releasing: 1998.7~
Base price, ¥: GF-TA3A
Body size: 4825x1770x1395
Interior (LxWxH): 1940x1460x1110
Wheelbase: 2745
Track f/r: 1520mm/1520mm
Full weight, kg: 1540
Body type: Sedan
Doors / seats: 4 door / 5

Safe equipment

Driver's air bag: ✓
Front passenger air bag: ✓
Side airbags: ×
ABS: ✓
TRC: ✓
Belts w/ tensioner: ×
Belts w/ effort limiter: ×
Belts w/ holding: ✓
Child-seat fixation: ✓
Safety planks: ✓
Brake assist: ×
Energy-absorbing body: ×
EBD: ×
Anti-theft device: ×
Additional equipment: ×

Comfort

Air conditioner: Full Auto
Power window: ✓
Central switch: ✓
Steering column length: ✓
Steering column height: ×
Cruise control: ✓
Leather steering wheel: ✓
Leather seats: —
Power front seat: ✓
Power rear seat: ×
Wood panel: ✓
Sunroof: シングル
Alloy wheels: 16 inches standard
Folding seat: ×
Glass w/ UV filter: ✓
Toned glasses: ×

Engine

Model: KJ-ZEM
Type: water cooling V-type 6 cylinder DOHC 24-valves
Bore x stroke, mm: 80.3x74.2
Engine size, cc: 2254
Compression ratio: 10.0
Fuel injection: EGI(電子制御燃料噴射装置)
Max power, hp/rpm: 220ps(162kW)/5500rpm
Max torque, Nm/rpm: 30.0kg m(294.2N m)/3500rpm
Supercharger: ×
Fuel tank, liters: 68 l
Fuel: Unleaded premium gasoline
Fuel consumption, l/100km: 10.5

Steering & suspension

Steering: Power assist equipped rack&pinion
Front suspension: Multi-link
Rear suspension: Multi-link
Front brake: Ventilated disk
Rear brake: disk
Front wheel: 215/55R16 91V
Rear wheel: 215/55R16 91V
Min turn diameter, m: 5.0

Gearbox

Number of stages: 4AT
Drive: FF
LSD: ----

Exterior equipment

Front fog lights: ✓
Rear fog lights: ×
Xenon: ×
Extra front lights: ×
Spoilers (f / r): × / ◯
Wiper: ×

Navigation & sound

Navigation: ✓
Navigation device: CD
Audio: AM/FM radio with CS player
CD player: 単装

Gear ratios

CVT	1	2	3	4	5	6	7	Rev	Main
—	2.785	1.545	1.000	0.694	—	—	—	—	2.272

Available colors

black / Other blackwhite / Other whitegreen / Other greenMaroon (brown)OliveNavy blue / Other Navy bluePurpleAshesYellowYellow-greenBlack (P)MagentaSilverRedBlueDark cyanPearl / Other PearlGold
