MAZDA ROADSTER RS

MAZDA ROADSTER

NCEC · RS

Description

Modification: RS
Chassis ID: NCEC
Dates releasing: 2006.12~
Base price, ¥: CBA-NCEC
Body size: 3995x1720x1245
Interior (LxWxH): 875x1415x1045
Wheelbase: 2330
Track f/r: 1490mm/1495mm
Full weight, kg: 1100
Body type: Open
Doors / seats: 2 door / 2

Safe equipment

Driver's air bag: ✓
Front passenger air bag: ✓
Side airbags: ◯
ABS: ✓
TRC: ×
Belts w/ tensioner: ✓
Belts w/ effort limiter: ✓
Belts w/ holding: ×
Child-seat fixation: ×
Safety planks: ✓
Brake assist: ×
Energy-absorbing body: 採用
EBD: ✓
Anti-theft device: ✓
Additional equipment: ×

Comfort

Air conditioner: Full Auto
Power window: ✓
Central switch: ✓
Steering column length: ×
Steering column height: ✓
Cruise control: ×
Leather steering wheel: ✓
Leather seats: —
Power front seat: ×
Power rear seat: ×
Wood panel: ×
Sunroof: ×
Alloy wheels: 17 inches standard
Folding seat: ×
Glass w/ UV filter: ✓
Toned glasses: ×

Engine

Model: LF-VE
Type: water cooling inline 4 cylinder DOHC 16-valves
Bore x stroke, mm: 87.5x83.1
Engine size, cc: 1998
Compression ratio: 10.8
Fuel injection: EGI(電子制御燃料噴射)
Max power, hp/rpm: 170ps(125kW)/6700rpm
Max torque, Nm/rpm: 19.3kg m(189N m)/5000rpm
Supercharger: ×
Fuel tank, liters: 50 l
Fuel: Unleaded premium gasoline
Fuel consumption, l/100km: 7.7

Steering & suspension

Steering: Power assist equipped rack&pinion
Front suspension: Double wishbone
Rear suspension: Multi-link
Front brake: Ventilated disk
Rear brake: disk
Front wheel: 205/45R17 84W
Rear wheel: 205/45R17 84W
Min turn diameter, m: 4.7

Gearbox

Number of stages: 6MT
Drive: FR
LSD: ✓

Exterior equipment

Front fog lights: ◯
Rear fog lights: ×
Xenon: ✓
Extra front lights: ×
Spoilers (f / r): × / ×
Wiper: ×

Navigation & sound

Navigation: ◯
Navigation device: HDD
Audio: AM/FMラジオ
CD player: 単装

Gear ratios

CVT	1	2	3	4	5	6	7	Rev	Main
—	3.815	2.260	1.640	1.177	1.000	0.832	—	—	3.603

Available colors

black / Brilliant Blackwhite / Other whitegreen / Other greenMaroon (brown) / Other Maroon (brown)OliveNavy bluePurpleAshes / Other AshesYellowYellow-greenBlack (P)MagentaSilver / Other SilverRed / Other RedBlue / Other BlueDark cyanPearlGold
