JDM Vehicle Catalog

Vehicle Specs

MERCEDES BENZ C CLASS SPORTS COUPE C180 KOMPRESSOR SPORT COUPE

MERCEDES BENZ C CLASS SPORTS COUPE

203746 · C180 KOMPRESSOR SPORT COUPE

Description

Modification: C180 KOMPRESSOR SPORT COUPE
Chassis ID: 203746
Dates releasing: 2003.9~
Base price, ¥: GH-203746
Body size: 4345x1730x1405
Interior (LxWxH): ----x----x----
Wheelbase: 2715
Track f/r: 1495mm/1465mm
Full weight, kg: 1450
Body type: Coupe
Doors / seats: 3 door / 4

Safe equipment

Driver's air bag: ✓
Front passenger air bag: ✓
Side airbags: ✓
ABS: ✓
TRC: ×
Belts w/ tensioner: ✓
Belts w/ effort limiter: ✓
Belts w/ holding: ✓
Child-seat fixation: ✓
Safety planks: ✓
Brake assist: ✓
Energy-absorbing body: ×
EBD: ×
Anti-theft device: ✓
Additional equipment: ESP(エレクトロニックスタビリティ PRO グラム)

Comfort

Air conditioner: Full Auto
Power window: ✓
Central switch: ✓
Steering column length: ✓
Steering column height: ✓
Cruise control: ✓
Leather steering wheel: ◯
Leather seats: —
Power front seat: ×
Power rear seat: ×
Wood panel: ×
Sunroof: ◯
Alloy wheels: Option settings YES
Folding seat: split
Glass w/ UV filter: ×
Toned glasses: ×

Engine

Model: 271
Type: inline 4 cylinder DOHCSチャージャ&
Bore x stroke, mm: 82.0x85.0
Engine size, cc: 1795
Compression ratio: 10.0
Fuel injection: 電子制御 type 燃料噴射
Max power, hp/rpm: 143ps(105kW)/5200rpm
Max torque, Nm/rpm: 22.4kg m(220N m)/2500~4200rpm
Supercharger: S charger
Fuel tank, liters: 62 l
Fuel: Unleaded premium gasoline
Fuel consumption, l/100km: 8.9

Steering & suspension

Steering: Power assist equipped rack&pinion
Front suspension: 3-link
Rear suspension: Multi-link
Front brake: Ventilated disk
Rear brake: disk
Front wheel: 205/55 R16
Rear wheel: 205/55 R16
Min turn diameter, m: 5.0

Gearbox

Number of stages: 5AT
Drive: FR
LSD: ----

Exterior equipment

Front fog lights: ✓
Rear fog lights: ✓
Xenon: ×
Extra front lights: ×
Spoilers (f / r): × / ×
Wiper: ×

Navigation & sound

Navigation: ◯
Navigation device: DVD
Audio: AM/FM radio with CS player
CD player: ×

Gear ratios

CVT	1	2	3	4	5	6	7	Rev	Main
—	3.951	2.423	1.486	1.000	0.833	—	—	—	3.147/1.930

Available colors

black / Obsidian Black (M)white / Other whitegreenMaroon (brown) / Other Maroon (brown)OliveNavy blue / Other Navy bluePurpleAshesYellowYellow-greenBlack (P)MagentaSilver / Sonic Chrome Brilliant Silver (M)Red / Other RedBlue / Other BlueDark cyanPearlGold
