JDM Vehicle Catalog

Vehicle Specs

MERCEDES BENZ CCLASS STATIONWAGON C240 STATIONWAGON

MERCEDES BENZ CCLASS STATIONWAGON

202086 · C240 STATIONWAGON

Description

Modification: C240 STATIONWAGON
Chassis ID: 202086
Dates releasing: 1997.8~
Base price, ¥: E-202086
Body size: 4525x1720x1460
Interior (LxWxH): ----x----x----
Wheelbase: 2690
Track f/r: 1500mm/1465mm
Full weight, kg: 1460
Body type: Wagon
Doors / seats: 5 door / 5

Safe equipment

Driver's air bag: ✓
Front passenger air bag: ✓
Side airbags: ✓
ABS: ✓
TRC: ✓
Belts w/ tensioner: ✓
Belts w/ effort limiter: ✓
Belts w/ holding: ✓
Child-seat fixation: ×
Safety planks: ✓
Brake assist: ✓
Energy-absorbing body: ×
EBD: ×
Anti-theft device: ×
Additional equipment: ASR(アクセレレーションスキッドコントロール)

Comfort

Air conditioner: Full Auto
Power window: ✓
Central switch: ✓
Steering column length: ✓
Steering column height: ×
Cruise control: ✓
Leather steering wheel: ✓
Leather seats: —
Power front seat: ✓
Power rear seat: ×
Wood panel: ✓
Sunroof: ◯
Alloy wheels: 15 inches standard
Folding seat: split
Glass w/ UV filter: ×
Toned glasses: ×

Engine

Model: 1121
Type: water cooling V-type 6 cylinder SOHC 18-valves
Bore x stroke, mm: 83.2x73.5
Engine size, cc: 2398
Compression ratio: 10.0
Fuel injection: 電子制御
Max power, hp/rpm: 170ps(125kW)/5900rpm
Max torque, Nm/rpm: 22.9kg m(224.6N m)/3000~5000rpm
Supercharger: ×
Fuel tank, liters: 62 l
Fuel: Unleaded premium gasoline
Fuel consumption, l/100km: 11.6

Steering & suspension

Steering: Other
Front suspension: Double wishbone
Rear suspension: Multi-link
Front brake: Ventilated disk
Rear brake: disk
Front wheel: 195/65R15
Rear wheel: 195/65R15
Min turn diameter, m: 4.9

Gearbox

Number of stages: 5AT
Drive: FR
LSD: ----

Exterior equipment

Front fog lights: ✓
Rear fog lights: ✓
Xenon: ×
Extra front lights: ×
Spoilers (f / r): × / ×
Wiper: ✓

Navigation & sound

Navigation: ◯
Navigation device: It is not
Audio: AM/FM radio with CS player
CD player: ×

Gear ratios

CVT	1	2	3	4	5	6	7	Rev	Main
—	—	—	—	—	—	—	—	—	----

Available colors

black / Other blackwhite / Other whitegreen / Other greenMaroon (brown)OliveNavy blue / Other Navy bluePurpleAshesYellowYellow-greenBlack (P)MagentaSilver / Other SilverRed / Other RedBlue / Other BlueDark cyanPearlGold
