MERCEDES BENZ CCLASS STATIONWAGON C240 STATIONWAGON SPORTLINE

MERCEDES BENZ CCLASS STATIONWAGON

203261 · C240 STATIONWAGON SPORTLINE

Description

Modification: C240 STATIONWAGON SPORTLINE
Chassis ID: 203261
Dates releasing: 2001.6~
Base price, ¥: GF-203261
Body size: 4550x1730x1450
Interior (LxWxH): ----x----x----
Wheelbase: 2715
Track f/r: 1495mm/1480mm
Full weight, kg: 1580
Body type: Wagon
Doors / seats: 5 door / 5

Safe equipment

Driver's air bag: ✓
Front passenger air bag: ✓
Side airbags: ✓
ABS: ✓
TRC: ×
Belts w/ tensioner: ✓
Belts w/ effort limiter: ✓
Belts w/ holding: ✓
Child-seat fixation: ✓
Safety planks: ✓
Brake assist: ✓
Energy-absorbing body: ×
EBD: ×
Anti-theft device: ✓
Additional equipment: エレクトロニックスタビリティ PRO グラム

Comfort

Air conditioner: Full Auto
Power window: ✓
Central switch: ✓
Steering column length: ✓
Steering column height: ✓
Cruise control: ✓
Leather steering wheel: ✓
Leather seats: —
Power front seat: ✓
Power rear seat: ×
Wood panel: ×
Sunroof: ◯
Alloy wheels: 17 inches standard
Folding seat: split
Glass w/ UV filter: ×
Toned glasses: ×

Engine

Model: 112M26
Type: V-type 6 cylinder SOHC 18-valves
Bore x stroke, mm: 89.9x68.2
Engine size, cc: 2597
Compression ratio: 10.5
Fuel injection: 電子制御 type 燃料噴射
Max power, hp/rpm: 170ps(125kW)/5500rpm
Max torque, Nm/rpm: 24.5kg m(240N m)/4500rpm
Supercharger: ×
Fuel tank, liters: 62 l
Fuel: Unleaded premium gasoline
Fuel consumption, l/100km: 11.9

Steering & suspension

Steering: Power assist equipped rack&pinion
Front suspension: 3-link
Rear suspension: Multi-link
Front brake: Ventilated disk
Rear brake: disk
Front wheel: 225/45ZR17
Rear wheel: 245/40ZR17
Min turn diameter, m: 5.0

Gearbox

Number of stages: 5AT
Drive: FR
LSD: ----

Exterior equipment

Front fog lights: ✓
Rear fog lights: ✓
Xenon: ✓
Extra front lights: ×
Spoilers (f / r): ✓ / ✓
Wiper: ✓

Navigation & sound

Navigation: ◯
Navigation device: DVD
Audio: AM/FM radio with CS player
CD player: 連装

Gear ratios

CVT	1	2	3	4	5	6	7	Rev	Main
—	3.951	2.423	1.486	1.000	0.833	—	—	—	3.147/1.930

Available colors

black / Other blackwhite / Other whitegreenMaroon (brown)OliveNavy bluePurpleAshesYellowYellow-greenBlack (P)MagentaSilver / Other SilverRedBlueDark cyanPearlGold
