JDM Vehicle Catalog

Vehicle Specs

MERCEDES BENZ CCLASS STATIONWAGON C280 STATIONWAGON AVANTGARDE

MERCEDES BENZ CCLASS STATIONWAGON

203254 · C280 STATIONWAGON AVANTGARDE

Description

Modification: C280 STATIONWAGON AVANTGARDE
Chassis ID: 203254
Dates releasing: 2007.1~
Base price, ¥: DBA-203254
Body size: 4550x1730x1465
Interior (LxWxH): ----x----x----
Wheelbase: 2715
Track f/r: 1495mm/1470mm
Full weight, kg: 1600
Body type: Wagon
Doors / seats: 5 door / 5

Safe equipment

Driver's air bag: ✓
Front passenger air bag: ✓
Side airbags: ✓
ABS: ✓
TRC: ×
Belts w/ tensioner: ✓
Belts w/ effort limiter: ✓
Belts w/ holding: ✓
Child-seat fixation: ×
Safety planks: ✓
Brake assist: ✓
Energy-absorbing body: ×
EBD: ×
Anti-theft device: ✓
Additional equipment: ESP(エレクトロニックスタビリティ PRO グラム)

Comfort

Air conditioner: Full Auto
Power window: ✓
Central switch: ✓
Steering column length: ✓
Steering column height: ✓
Cruise control: ✓
Leather steering wheel: ✓
Leather seats: —
Power front seat: ✓
Power rear seat: ×
Wood panel: ✓
Sunroof: ◯
Alloy wheels: 17 inches standard
Folding seat: split
Glass w/ UV filter: ×
Toned glasses: ✓

Engine

Model: 272M30
Type: V-type 6 cylinder DOHC
Bore x stroke, mm: 88.0x82.1
Engine size, cc: 2996
Compression ratio: 11.3
Fuel injection: 電子制御
Max power, hp/rpm: 231ps(170kW)/6000rpm
Max torque, Nm/rpm: 30.6kg m(300N m)/3500~4000rpm
Supercharger: ×
Fuel tank, liters: 62 l
Fuel: Unleaded premium gasoline
Fuel consumption, l/100km: 10.5

Steering & suspension

Steering: Power assist equipped rack&pinion
Front suspension: 3-link
Rear suspension: Multi-link
Front brake: Ventilated disk
Rear brake: disk
Front wheel: 225/45R17
Rear wheel: 245/40R17
Min turn diameter, m: 5.0

Gearbox

Number of stages: 7AT
Drive: FR
LSD: ----

Exterior equipment

Front fog lights: ✓
Rear fog lights: ✓
Xenon: ✓
Extra front lights: ×
Spoilers (f / r): × / ×
Wiper: ✓

Navigation & sound

Navigation: ✓
Navigation device: DVD
Audio: AM/FMラジオ
CD player: 連装

Gear ratios

CVT	1	2	3	4	5	6	7	Rev	Main
—	—	—	—	—	—	—	—	—	----

Available colors

black / Other blackwhite / Other whitegreen / Other greenMaroon (brown) / Other Maroon (brown)OliveNavy blue / Other Navy bluePurpleAshes / Other AshesYellowYellow-greenBlack (P)MagentaSilver / Other SilverRed / Other RedBlue / Other BlueDark cyanPearlGold
