MERCEDES BENZ SCLASS 560SEL

MERCEDES BENZ SCLASS

126039 · 560SEL

Description

Modification: 560SEL
Chassis ID: 126039
Dates releasing: 1990.8~
Base price, ¥: E-126039
Body size: 5160x1820x1445
Interior (LxWxH): ----x----x----
Wheelbase: 3070
Track f/r: 1555mm/1525mm
Full weight, kg: 1790
Body type: Sedan
Doors / seats: 4 door / 5

Safe equipment

Driver's air bag: ✓
Front passenger air bag: ◯
Side airbags: ×
ABS: ✓
TRC: ×
Belts w/ tensioner: ×
Belts w/ effort limiter: ×
Belts w/ holding: ✓
Child-seat fixation: ×
Safety planks: ×
Brake assist: ×
Energy-absorbing body: ×
EBD: ×
Anti-theft device: ×
Additional equipment: ASR(アクセレレーションスキッドコントロール)

Comfort

Air conditioner: Full Auto
Power window: ✓
Central switch: ✓
Steering column length: ✓
Steering column height: ×
Cruise control: ✓
Leather steering wheel: ×
Leather seats: —
Power front seat: ✓
Power rear seat: ✓
Wood panel: ×
Sunroof: シングル
Alloy wheels: 15 inches standard
Folding seat: ×
Glass w/ UV filter: ×
Toned glasses: ×

Engine

Model: 1178
Type: V-type 8 cylinder OHC
Bore x stroke, mm: 96.5x94.8
Engine size, cc: 5546
Compression ratio: 10.0
Fuel injection: KEジェトロニック
Max power, hp/rpm: 285ps(----kW)/5200rpm
Max torque, Nm/rpm: 44.8kg m(----N m)/3750rpm
Supercharger: ×
Fuel tank, liters: 90 l
Fuel: Unleaded premium gasoline
Fuel consumption, l/100km: 19.6

Steering & suspension

Steering: Other
Front suspension: Double wishbone /コイル
Rear suspension: セミトレーリングアーム/ Coil spring
Front brake: Ventilated disk
Rear brake: disk
Front wheel: 205/65 R15 94V
Rear wheel: 205/65 R15 94V
Min turn diameter, m: 5.8

Gearbox

Number of stages: 4AT
Drive: FR
LSD: ----

Exterior equipment

Front fog lights: ✓
Rear fog lights: ✓
Xenon: ×
Extra front lights: ×
Spoilers (f / r): × / ×
Wiper: ×

Navigation & sound

Navigation: ×
Navigation device: It is not
Audio: AM/FM radio with CS player
CD player: ×

Gear ratios

CVT	1	2	3	4	5	6	7	Rev	Main
—	—	—	—	—	—	—	—	—	----

Available colors

blackwhitegreenMaroon (brown)OliveNavy bluePurpleAshesYellowYellow-greenBlack (P)MagentaSilverRedBlueDark cyanPearlGold
