MERCEDES BENZ VCLASS V230

MERCEDES BENZ VCLASS

638230 · V230

Description

Modification: V230
Chassis ID: 638230
Dates releasing: 2000.4~
Base price, ¥: GF-638230
Body size: 4670x1890x1890
Interior (LxWxH): ----x----x----
Wheelbase: 3000
Track f/r: 1620mm/1630mm
Full weight, kg: 1990
Body type: MV 1Box
Doors / seats: 5 door / 6

Safe equipment

Driver's air bag: ✓
Front passenger air bag: ✓
Side airbags: ×
ABS: ✓
TRC: ×
Belts w/ tensioner: ✓
Belts w/ effort limiter: ×
Belts w/ holding: ✓
Child-seat fixation: ×
Safety planks: ×
Brake assist: ×
Energy-absorbing body: ×
EBD: ×
Anti-theft device: ×
Additional equipment: ×

Comfort

Air conditioner: Full Auto
Power window: ✓
Central switch: ✓
Steering column length: ✓
Steering column height: ✓
Cruise control: ×
Leather steering wheel: ◯
Leather seats: —
Power front seat: ×
Power rear seat: ×
Wood panel: ×
Sunroof: ◯
Alloy wheels: 15 inches standard
Folding seat: split
Glass w/ UV filter: ×
Toned glasses: ×

Engine

Model: 1118
Type: inline 4 cylinder DOHC
Bore x stroke, mm: 90.9x88.4
Engine size, cc: 2294
Compression ratio: 10.4
Fuel injection: 電子制御
Max power, hp/rpm: 143ps(105kW)/5000rpm
Max torque, Nm/rpm: 21.9kg m(214.8N m)/3500~4500rpm
Supercharger: ×
Fuel tank, liters: 78 l
Fuel: Unleaded premium gasoline
Fuel consumption, l/100km: 13

Steering & suspension

Steering: Power assist equipped rack&pinion
Front suspension: ウィッシュボーンロアアーム+ McPherson Strut
Rear suspension: セミトレーリングアーム
Front brake: Ventilated disk
Rear brake: disk
Front wheel: 215/65R15
Rear wheel: 215/65R15
Min turn diameter, m: 5.8

Gearbox

Number of stages: 4AT
Drive: FF
LSD: ----

Exterior equipment

Front fog lights: ✓
Rear fog lights: ✓
Xenon: ×
Extra front lights: ×
Spoilers (f / r): × / ×
Wiper: ✓

Navigation & sound

Navigation: ◯
Navigation device: It is not
Audio: AM/FM radio with CS player
CD player: ×

Gear ratios

CVT	1	2	3	4	5	6	7	Rev	Main
—	2.718	1.481	1.000	0.720	—	—	—	—	2.568

Available colors

blackwhite / Other whitegreenMaroon (brown) / Other Maroon (brown)OliveNavy bluePurpleAshesYellowYellow-greenBlack (P) / Other Black (P)MagentaSilver / Other SilverRed / Other RedBlueDark cyan / Other Dark cyanPearlGold
