JDM Vehicle Catalog

Vehicle Specs

MG TF135 Trim

MG TF135

RD18K · —

Description

Modification: —
Chassis ID: RD18K
Dates releasing: 2003.7~
Base price, ¥: GH-RD18K
Body size: 3950x1630x1260
Interior (LxWxH): ----x----x----
Wheelbase: 2380
Track f/r: 1410mm/1410mm
Full weight, kg: ----
Body type: Open
Doors / seats: 2 door / 2

Safe equipment

Driver's air bag: ✓
Front passenger air bag: ✓
Side airbags: ×
ABS: ✓
TRC: ×
Belts w/ tensioner: ×
Belts w/ effort limiter: ×
Belts w/ holding: ×
Child-seat fixation: ×
Safety planks: ✓
Brake assist: ×
Energy-absorbing body: ×
EBD: ×
Anti-theft device: ✓
Additional equipment: ×

Comfort

Air conditioner: Manual
Power window: ✓
Central switch: ✓
Steering column length: ×
Steering column height: ✓
Cruise control: ×
Leather steering wheel: ✓
Leather seats: —
Power front seat: ×
Power rear seat: ×
Wood panel: ×
Sunroof: ×
Alloy wheels: 16 inches standard
Folding seat: ×
Glass w/ UV filter: ×
Toned glasses: ✓

Engine

Model: K
Type: inline 4 cylinder DOHC 16-valves
Bore x stroke, mm: ----x----
Engine size, cc: 1796
Compression ratio: ----
Fuel injection: マルチポイントインジェクション
Max power, hp/rpm: 136ps(100kW)/6750rpm
Max torque, Nm/rpm: 16.8kg m(165N m)/5000rpm
Supercharger: ×
Fuel tank, liters: 50 l
Fuel: Unleaded premium gasoline
Fuel consumption, l/100km: 11.1

Steering & suspension

Steering: Power assist equipped rack&pinion
Front suspension: Double wishbone type Coil spring (アンチロールバー)
Rear suspension: Multi-link Coil spring (アンチロールバー)
Front brake: Ventilated disk
Rear brake: disk
Front wheel: 195/45 ZR16
Rear wheel: 215/40 ZR16
Min turn diameter, m: ----

Gearbox

Number of stages: 5MT
Drive: Mid-ship
LSD: ----

Exterior equipment

Front fog lights: ✓
Rear fog lights: ✓
Xenon: ×
Extra front lights: ✓
Spoilers (f / r): × / ×
Wiper: ×

Navigation & sound

Navigation: ×
Navigation device: It is not
Audio: It is not
CD player: ×

Gear ratios

CVT	1	2	3	4	5	6	7	Rev	Main
—	3.166	1.842	1.307	1.033	0.765	—	—	—	3.000

Available colors

black / Other blackwhite / Other whitegreen / Other greenMaroon (brown)OliveNavy blue / Other Navy bluePurpleAshes / Other AshesYellow / Other YellowYellow-greenBlack (P)MagentaSilver / Other SilverRed / Other RedBlue / Other BlueDark cyanPearlGold / Other Gold
