MITSUBISHI DIAMANTE WAGON LS

MITSUBISHI DIAMANTE WAGON

F36W · LS

Description

Modification: LS
Chassis ID: F36W
Dates releasing: 1997.10~
Base price, ¥: E-F36W
Body size: 4810x1785x1500
Interior (LxWxH): 1940x1490x1140
Wheelbase: 2720
Track f/r: 1545mm/1505mm
Full weight, kg: 1630
Body type: Wagon
Doors / seats: 5 door / 5

Safe equipment

Driver's air bag: ✓
Front passenger air bag: ✓
Side airbags: ×
ABS: ✓
TRC: ✓
Belts w/ tensioner: ✓
Belts w/ effort limiter: ×
Belts w/ holding: ✓
Child-seat fixation: ✓
Safety planks: ✓
Brake assist: ×
Energy-absorbing body: ×
EBD: ×
Anti-theft device: ×
Additional equipment: ×

Comfort

Air conditioner: Full Auto
Power window: ✓
Central switch: ✓
Steering column length: ×
Steering column height: ✓
Cruise control: ✓
Leather steering wheel: ×
Leather seats: —
Power front seat: ✓
Power rear seat: ×
Wood panel: ✓
Sunroof: シングル
Alloy wheels: 16 inches standard
Folding seat: split
Glass w/ UV filter: ×
Toned glasses: ✓

Engine

Model: 6G7
Type: V-type 6 cylinder SOHC 24-valves
Bore x stroke, mm: 91.1x76.0
Engine size, cc: 2972
Compression ratio: 9.0
Fuel injection: ECI-MULTI(電子制御燃料噴射)
Max power, hp/rpm: 200ps(147kW)/5500rpm
Max torque, Nm/rpm: 28.0kg m(274.6N m)/4500rpm
Supercharger: ×
Fuel tank, liters: 71 l
Fuel: Regular unleaded gasoline
Fuel consumption, l/100km: 0

Steering & suspension

Steering: Power assist equipped rack&pinion
Front suspension: McPherson Strut type
Rear suspension: 5-link
Front brake: Ventilated disk
Rear brake: disk
Front wheel: 215/60R16 95H
Rear wheel: 215/60R16 95H
Min turn diameter, m: 5.6

Gearbox

Number of stages: 5AT
Drive: FF
LSD: ----

Exterior equipment

Front fog lights: ✓
Rear fog lights: ×
Xenon: ×
Extra front lights: ×
Spoilers (f / r): ◯ / ✓
Wiper: ✓

Navigation & sound

Navigation: ×
Navigation device: It is not
Audio: AM/FM radio with CS player
CD player: 連装

Gear ratios

CVT	1	2	3	4	5	6	7	Rev	Main
—	3.789	2.057	1.421	1.000	0.731	—	—	—	3.865

Available colors

blackwhitegreen / Other greenMaroon (brown)OliveNavy bluePurpleAshesYellowYellow-greenBlack (P)MagentaSilverRedBlueDark cyanPearlGold / Other Gold
