JDM Vehicle Catalog

Vehicle Specs

MITSUBISHI DION TURBO

MITSUBISHI DION

CR5W · TURBO

Description

Modification: TURBO
Chassis ID: CR5W
Dates releasing: 2002.5~
Base price, ¥: TA-CR5W
Body size: 4460x1695x1650
Interior (LxWxH): 2435x1420x1265
Wheelbase: 2705
Track f/r: 1470mm/1470mm
Full weight, kg: 1400
Body type: MV 1Box
Doors / seats: 5 door / 7

Safe equipment

Driver's air bag: ✓
Front passenger air bag: ✓
Side airbags: ×
ABS: ✓
TRC: ×
Belts w/ tensioner: ✓
Belts w/ effort limiter: ✓
Belts w/ holding: ✓
Child-seat fixation: ✓
Safety planks: ✓
Brake assist: ✓
Energy-absorbing body: 採用
EBD: ✓
Anti-theft device: ✓
Additional equipment: ×

Comfort

Air conditioner: Dual air conditioning
Power window: ✓
Central switch: ✓
Steering column length: ×
Steering column height: ✓
Cruise control: ×
Leather steering wheel: ×
Leather seats: —
Power front seat: ×
Power rear seat: ×
Wood panel: ✓
Sunroof: ◯
Alloy wheels: 15 inches standard
Folding seat: split
Glass w/ UV filter: ✓
Toned glasses: ✓

Engine

Model: 4G93 GDI
Type: inline 4 cylinder DOHC 16-valves IC-turbo
Bore x stroke, mm: 81.0x89.0
Engine size, cc: 1834
Compression ratio: 10.0
Fuel injection: 筒内直接噴射
Max power, hp/rpm: 165ps(121kW)/5500rpm
Max torque, Nm/rpm: 22.4kg m(220N m)/3500rpm
Supercharger: IC turbo
Fuel tank, liters: 60 l
Fuel: Unleaded premium gasoline
Fuel consumption, l/100km: 0

Steering & suspension

Steering: Power assist equipped rack&pinion
Front suspension: McPherson Strut type
Rear suspension: Multi-link
Front brake: Ventilated disk
Rear brake: Drum
Front wheel: 195/60R15
Rear wheel: 195/60R15
Min turn diameter, m: 5.2

Gearbox

Number of stages: 4AT
Drive: FF
LSD: ----

Exterior equipment

Front fog lights: ◯
Rear fog lights: ×
Xenon: ◯
Extra front lights: ×
Spoilers (f / r): ◯ / ✓
Wiper: ✓

Navigation & sound

Navigation: ×
Navigation device: It is not
Audio: It is not
CD player: ×

Gear ratios

CVT	1	2	3	4	5	6	7	Rev	Main
—	2.842	1.529	1.000	0.712	—	—	—	—	2.480

Available colors

black / Other blackwhitegreenMaroon (brown) / Other Maroon (brown)OliveNavy blue / Other Navy bluePurpleAshesYellowYellow-green / Other Yellow-greenBlack (P)MagentaSilver / Other SilverRedBlueDark cyanPearl / Other PearlGold / Other Gold
