MITSUBISHI ETERNA SIGMA CS EXTRA

MITSUBISHI ETERNA SIGMA

E17A · CS EXTRA

Description

Modification: CS EXTRA
Chassis ID: E17A
Dates releasing: 1988.10~
Base price, ¥: E-E17A
Body size: 4660x1695x1375
Interior (LxWxH): 1935x1385x1120
Wheelbase: 2600
Track f/r: 1445mm/1415mm
Full weight, kg: 1290
Body type: Hardtop
Doors / seats: 4 door / 5

Safe equipment

Driver's air bag: ×
Front passenger air bag: ×
Side airbags: ×
ABS: ×
TRC: ×
Belts w/ tensioner: ×
Belts w/ effort limiter: ×
Belts w/ holding: ×
Child-seat fixation: ×
Safety planks: ×
Brake assist: ×
Energy-absorbing body: ×
EBD: ×
Anti-theft device: ×
Additional equipment: ×

Comfort

Air conditioner: Manual
Power window: ✓
Central switch: ✓
Steering column length: ×
Steering column height: ✓
Cruise control: ✓
Leather steering wheel: ×
Leather seats: —
Power front seat: ×
Power rear seat: ×
Wood panel: ×
Sunroof: ◯
Alloy wheels: 14 inches standard
Folding seat: ×
Glass w/ UV filter: ×
Toned glasses: ×

Engine

Model: 6G71ECI-MULTI
Type: V-type 6 cylinder OHC
Bore x stroke, mm: 74.7x76.0
Engine size, cc: 1998
Compression ratio: 8.9
Fuel injection: ECI-MULTI(電子制御燃料噴射)
Max power, hp/rpm: 105ps(77kW)/5000rpm
Max torque, Nm/rpm: 16.1kg m(157.9N m)/4000rpm
Supercharger: ×
Fuel tank, liters: 60 l
Fuel: Regular unleaded gasoline
Fuel consumption, l/100km: 0

Steering & suspension

Steering: Power assist equipped rack&pinion
Front suspension: McPherson Strut
Rear suspension: 3-link トーションアクスル
Front brake: Ventilated disk
Rear brake: Ventilated disk
Front wheel: 185/70R14 87S
Rear wheel: 185/70R14 87S
Min turn diameter, m: 5.3

Gearbox

Number of stages: 4AT
Drive: FF
LSD: ----

Exterior equipment

Front fog lights: ×
Rear fog lights: ×
Xenon: ×
Extra front lights: ×
Spoilers (f / r): × / ×
Wiper: ×

Navigation & sound

Navigation: ×
Navigation device: It is not
Audio: AM/FM radio with CS player
CD player: ×

Gear ratios

CVT	1	2	3	4	5	6	7	Rev	Main
—	2.846	1.581	1.000	0.685	—	—	—	—	2.176

Available colors

blackwhite / Other whitegreenMaroon (brown) / Other Maroon (brown)OliveNavy blue / Other Navy bluePurpleAshesYellowYellow-greenBlack (P)MagentaSilverRedBlueDark cyanPearl / Other PearlGold
