JDM Vehicle Catalog

Vehicle Specs

MITSUBISHI PAJERO IO ZR-S

MITSUBISHI PAJERO IO

H76W Β· ZR-S

Description

Modification
ZR-S
Chassis ID
H76W
Dates releasing
1999.8~
Base price, ¥
GF-H76W
Body size
3975x1680x1710
Interior (LxWxH)
1620x1400x1225
Wheelbase
2450
Track f/r
1435mm/1445mm
Full weight, kg
1340
Body type
SUV
Doors / seats
5 door / 5

Safe equipment

Driver's air bag
✓
Front passenger air bag
✓
Side airbags
◯
ABS
✓
TRC
×
Belts w/ tensioner
×
Belts w/ effort limiter
✓
Belts w/ holding
✓
Child-seat fixation
✓
Safety planks
✓
Brake assist
×
Energy-absorbing body
×
EBD
×
Anti-theft device
×
Additional equipment
×

Comfort

Air conditioner
Full Auto
Power window
✓
Central switch
✓
Steering column length
×
Steering column height
×
Cruise control
×
Leather steering wheel
✓
Leather seats
—
Power front seat
×
Power rear seat
×
Wood panel
×
Sunroof
◯
Alloy wheels
16 inches standard
Folding seat
split
Glass w/ UV filter
✓
Toned glasses
✓

Engine

Model
4G93
Type
inline 4 cylinder DOHC 16-valves
Bore x stroke, mm
81.0x89.0
Engine size, cc
1834
Compression ratio
12.0
Fuel injection
GDI(ガソγƒͺン筒内直ζŽ₯ε™΄ε°„)
Max power, hp/rpm
130ps(96kW)/5500rpm
Max torque, Nm/rpm
18.5kg m(181.4N m)/3500rpm
Supercharger
×
Fuel tank, liters
53 l
Fuel
Unleaded premium gasoline
Fuel consumption, l/100km
0

Steering & suspension

Steering
Power assist equipped rack&pinion
Front suspension
McPherson Strut type Coil spring
Rear suspension
5-link Coil spring
Front brake
Ventilated disk
Rear brake
Drum
Front wheel
215/70R16
Rear wheel
215/70R16
Min turn diameter, m
5.2

Gearbox

Number of stages
4AT
Drive
Full-time 4WD
LSD
◯

Exterior equipment

Front fog lights
◯
Rear fog lights
×
Xenon
×
Extra front lights
×
Spoilers (f / r)
× / ◯
Wiper
✓

Navigation & sound

Navigation
✓
Navigation device
CD
Audio
AM/FM radio with CS player
CD player
×

Gear ratios

CVT1234567RevMain
—2.8261.4931.0000.730————2.703

Available colors

black / Other blackwhite / Other whitegreen / Other greenMaroon (brown)OliveNavy bluePurpleAshesYellowYellow-greenBlack (P)MagentaSilver / Other SilverRed / Other RedBlue / Other BlueDark cyanPearl / Other PearlGold / Other Gold
