MITSUBISHI PAJERO MINI DUKE

MITSUBISHI PAJERO MINI

H58A · DUKE

Description

Modification: DUKE
Chassis ID: H58A
Dates releasing: 2002.9~
Base price, ¥: TA-H58A
Body size: 3395x1475x1670
Interior (LxWxH): 1590x1220x1210
Wheelbase: 2280
Track f/r: 1270mm/1270mm
Full weight, kg: 980
Body type: Key SUV
Doors / seats: 3 door / 4

Safe equipment

Driver's air bag: ✓
Front passenger air bag: ✓
Side airbags: ×
ABS: ✓
TRC: ×
Belts w/ tensioner: ✓
Belts w/ effort limiter: ✓
Belts w/ holding: ✓
Child-seat fixation: ✓
Safety planks: ✓
Brake assist: ✓
Energy-absorbing body: 採用
EBD: ×
Anti-theft device: ×
Additional equipment: ×

Comfort

Air conditioner: Manual
Power window: ✓
Central switch: ✓
Steering column length: ×
Steering column height: ×
Cruise control: ×
Leather steering wheel: ×
Leather seats: —
Power front seat: ×
Power rear seat: ×
Wood panel: ×
Sunroof: ◯
Alloy wheels: 15 inches standard
Folding seat: split
Glass w/ UV filter: ✓
Toned glasses: ✓

Engine

Model: 4A30インタークーラ&#12
Type: inline 4 cylinder SOHC 16-valves IC-turbo
Bore x stroke, mm: 60.0x58.3
Engine size, cc: 659
Compression ratio: 8.5
Fuel injection: ECIマルチ(電子制御燃料噴射)
Max power, hp/rpm: 64ps(47kW)/6000rpm
Max torque, Nm/rpm: 9.0kg m(88N m)/4000rpm
Supercharger: IC turbo
Fuel tank, liters: 43 l
Fuel: Regular unleaded gasoline
Fuel consumption, l/100km: 0

Steering & suspension

Steering: Power assist equipped rack&pinion
Front suspension: McPherson Strut type Coil spring
Rear suspension: 5-link Coil spring
Front brake: Ventilated disk
Rear brake: Drum
Front wheel: 175/80R15
Rear wheel: 175/80R15
Min turn diameter, m: 4.8

Gearbox

Number of stages: 5MT
Drive: Part-time 4WD
LSD: ◯

Exterior equipment

Front fog lights: ✓
Rear fog lights: ×
Xenon: ×
Extra front lights: ×
Spoilers (f / r): ✓ / ✓
Wiper: ✓

Navigation & sound

Navigation: ◯
Navigation device: It is not
Audio: It is not
CD player: ×

Gear ratios

CVT	1	2	3	4	5	6	7	Rev	Main
—	4.200	2.450	1.524	1.000	0.807	—	—	—	3.776

Available colors

black / black micawhite / White solidgreenMaroon (brown)OliveNavy bluePurpleAshesYellowYellow-greenBlack (P)MagentaSilver / Other SilverRedBlueDark cyanPearlGold
