NISSAN CARAVAN ELGRAND J

NISSAN CARAVAN ELGRAND

ALE50 · J

Description

Modification: J
Chassis ID: ALE50
Dates releasing: 1997.5~
Base price, ¥: E-ALE50
Body size: 4740x1775x1940
Interior (LxWxH): 3030x1645x1290
Wheelbase: 2900
Track f/r: 1510mm/1515mm
Full weight, kg: 1930
Body type: MV 1Box
Doors / seats: 4 door / 8

Safe equipment

Driver's air bag: ✓
Front passenger air bag: ✓
Side airbags: ×
ABS: ✓
TRC: ×
Belts w/ tensioner: ✓
Belts w/ effort limiter: ✓
Belts w/ holding: ✓
Child-seat fixation: ✓
Safety planks: ✓
Brake assist: ×
Energy-absorbing body: 採用
EBD: ×
Anti-theft device: ×
Additional equipment: ×

Comfort

Air conditioner: Dual air conditioning
Power window: ✓
Central switch: ✓
Steering column length: ×
Steering column height: ✓
Cruise control: ×
Leather steering wheel: ×
Leather seats: —
Power front seat: ×
Power rear seat: ×
Wood panel: ◯
Sunroof: ◯
Alloy wheels: Option settings YES
Folding seat: ×
Glass w/ UV filter: ✓
Toned glasses: ×

Engine

Model: VG33E
Type: V-type 6 cylinder OHC
Bore x stroke, mm: 91.5x83.0
Engine size, cc: 3274
Compression ratio: 8.9
Fuel injection: ニッサンEGI(ECCS)
Max power, hp/rpm: 170ps(125kW)/4800rpm
Max torque, Nm/rpm: 27.1kg m(265.8N m)/2800rpm
Supercharger: ×
Fuel tank, liters: 76 l
Fuel: Regular unleaded gasoline
Fuel consumption, l/100km: 13.9

Steering & suspension

Steering: Power assist equipped rack&pinion
Front suspension: Strut type
Rear suspension: コントロールロッド付5リンク Coil spring
Front brake: Ventilated disk
Rear brake: Drum
Front wheel: 215/65R15 96S
Rear wheel: 215/65R15 96S
Min turn diameter, m: 5.6

Gearbox

Number of stages: 4AT
Drive: FR
LSD: ----

Exterior equipment

Front fog lights: ✓
Rear fog lights: ×
Xenon: ×
Extra front lights: ×
Spoilers (f / r): ◯ / ◯
Wiper: ✓

Navigation & sound

Navigation: ◯
Navigation device: It is not
Audio: AM/FMラジオ
CD player: ×

Gear ratios

CVT	1	2	3	4	5	6	7	Rev	Main
—	2.785	1.545	1.000	0.694	—	—	—	—	2.272

Available colors

black / Other blackwhitegreenMaroon (brown)OliveNavy bluePurpleAshesYellowYellow-green / Other Yellow-greenBlack (P)MagentaSilverRedBlueDark cyan / Other Dark cyanPearl / Other PearlGold
