JDM Vehicle Catalog

Vehicle Specs

NISSAN CEDRIC CIMA TYPE II

NISSAN CEDRIC CIMA

FPAY31 · TYPE II

Description

Modification: TYPE II
Chassis ID: FPAY31
Dates releasing: 1989.8~
Base price, ¥: E-FPAY31
Body size: 4890x1770x1380
Interior (LxWxH): 1950x1460x1150
Wheelbase: 2735
Track f/r: 1500mm/1520mm
Full weight, kg: 1600
Body type: Hardtop
Doors / seats: 4 door / 5

Safe equipment

Driver's air bag: ×
Front passenger air bag: ×
Side airbags: ×
ABS: ✓
TRC: ×
Belts w/ tensioner: ×
Belts w/ effort limiter: ×
Belts w/ holding: ✓
Child-seat fixation: ×
Safety planks: ×
Brake assist: ×
Energy-absorbing body: ×
EBD: ×
Anti-theft device: ×
Additional equipment: ×

Comfort

Air conditioner: Dual air conditioning
Power window: ✓
Central switch: ✓
Steering column length: ✓
Steering column height: ✓
Cruise control: ✓
Leather steering wheel: ✓
Leather seats: —
Power front seat: ✓
Power rear seat: ✓
Wood panel: ×
Sunroof: ◯
Alloy wheels: 15 inches standard
Folding seat: ×
Glass w/ UV filter: ×
Toned glasses: ×

Engine

Model: VG30DE
Type: V-type 6 cylinder DOHC 24-valves
Bore x stroke, mm: 87.0x83.0
Engine size, cc: 2960
Compression ratio: 10.5
Fuel injection: ECCS
Max power, hp/rpm: 200ps(147kW)/6000rpm
Max torque, Nm/rpm: 26.5kg m(259.9N m)/4400rpm
Supercharger: ×
Fuel tank, liters: 72 l
Fuel: Unleaded premium gasoline
Fuel consumption, l/100km: 12.5

Steering & suspension

Steering: Power assist equipped rack&pinion
Front suspension: Independent suspension Strut type
Rear suspension: Independent suspension セミトレーリングアーム
Front brake: Ventilated disk
Rear brake: Ventilated disk
Front wheel: 205/65R15 93H
Rear wheel: 205/65R15 93H
Min turn diameter, m: 5.5

Gearbox

Number of stages: 4AT
Drive: FR
LSD: ✓

Exterior equipment

Front fog lights: ✓
Rear fog lights: ×
Xenon: ×
Extra front lights: ×
Spoilers (f / r): × / ×
Wiper: ×

Navigation & sound

Navigation: ◯
Navigation device: It is not
Audio: AM/FM radio with CS player
CD player: ×

Gear ratios

CVT	1	2	3	4	5	6	7	Rev	Main
—	2.785	1.545	1.000	0.694	—	—	—	—	2.272

Available colors

black / Other blackwhite / Other whitegreen / Other greenMaroon (brown) / Other Maroon (brown)Olive / Other OliveNavy blue / Other Navy bluePurpleAshesYellowYellow-greenBlack (P) / Other Black (P)MagentaSilverRed / Other RedBlue / Other BlueDark cyanPearl / Other PearlGold / Other Gold
