OPEL ASTRA WAGON 2.0 TURBO SPORT

OPEL ASTRA

AH04Z20W · WAGON 2.0 TURBO SPORT

Description

Modification: WAGON 2.0 TURBO SPORT
Chassis ID: AH04Z20W
Dates releasing: 2005.1~
Base price, ¥: GH-AH04Z20W
Body size: 4520x1760x1475
Interior (LxWxH): 1755x1315x1190
Wheelbase: 2705
Track f/r: 1475mm/1465mm
Full weight, kg: 1390
Body type: Wagon
Doors / seats: 5 door / 5

Safe equipment

Driver's air bag: ✓
Front passenger air bag: ✓
Side airbags: ✓
ABS: ✓
TRC: ✓
Belts w/ tensioner: ✓
Belts w/ effort limiter: ✓
Belts w/ holding: ✓
Child-seat fixation: ×
Safety planks: ✓
Brake assist: ✓
Energy-absorbing body: ×
EBD: ✓
Anti-theft device: ✓
Additional equipment: FPS(フット PRO テクションシステム) DSA(ダイナミックセーフティ)サスペンショ&#125

Comfort

Air conditioner: Full Auto
Power window: ✓
Central switch: ✓
Steering column length: ✓
Steering column height: ✓
Cruise control: ×
Leather steering wheel: ✓
Leather seats: —
Power front seat: ×
Power rear seat: ×
Wood panel: ×
Sunroof: ◯
Alloy wheels: 17 inches standard
Folding seat: split
Glass w/ UV filter: ×
Toned glasses: ×

Engine

Model: Z20
Type: inline 4 cylinder DOHCturbo
Bore x stroke, mm: 86.0x86.0
Engine size, cc: 1998
Compression ratio: 8.8
Fuel injection: 電子制御燃料噴射
Max power, hp/rpm: 200ps(147kW)/5400rpm
Max torque, Nm/rpm: 26.7kg m(262N m)/4200rpm
Supercharger: Turbo
Fuel tank, liters: 52 l
Fuel: Unleaded premium gasoline
Fuel consumption, l/100km: 8.1

Steering & suspension

Steering: Power assist equipped rack&pinion
Front suspension: McPherson Strut
Rear suspension: トーションビームトレーリングアー
Front brake: Ventilated disk
Rear brake: disk
Front wheel: 215/45 R17 91V
Rear wheel: 215/45 R17 91V
Min turn diameter, m: 5.4

Gearbox

Number of stages: 6MT
Drive: FF
LSD: ----

Exterior equipment

Front fog lights: ✓
Rear fog lights: ✓
Xenon: ✓
Extra front lights: ×
Spoilers (f / r): ◯ / ◯
Wiper: ✓

Navigation & sound

Navigation: ◯
Navigation device: HDD
Audio: AM/FMラジオ
CD player: 連装

Gear ratios

CVT	1	2	3	4	5	6	7	Rev	Main
—	3.818	2.158	1.460	1.073	0.865	0.744	—	—	3.545

Available colors

black / Other blackwhitegreenMaroon (brown)OliveNavy bluePurpleAshesYellowYellow-greenBlack (P)MagentaSilver / Other SilverRed / Other RedBlueDark cyanPearlGold
