OPEL SIGNUM 2.2

OPEL SIGNUM

Z02Z22L · 2.2

Description

Modification: 2.2
Chassis ID: Z02Z22L
Dates releasing: 2003.12~
Base price, ¥: TA-Z02Z22L
Body size: 4635x1800x1460
Interior (LxWxH): ----x----x----
Wheelbase: 2830
Track f/r: 1520mm/1515mm
Full weight, kg: 1510
Body type: Wagon
Doors / seats: 5 door / 5

Safe equipment

Driver's air bag: ✓
Front passenger air bag: ✓
Side airbags: ✓
ABS: ✓
TRC: ✓
Belts w/ tensioner: ✓
Belts w/ effort limiter: ✓
Belts w/ holding: ✓
Child-seat fixation: ×
Safety planks: ✓
Brake assist: ✓
Energy-absorbing body: ×
EBD: ✓
Anti-theft device: ✓
Additional equipment: ESPプラス(エレクトロニックスタビリティ PRO グラム)CBC(コーナリングブレー&#12461

Comfort

Air conditioner: Full Auto
Power window: ✓
Central switch: ✓
Steering column length: ✓
Steering column height: ✓
Cruise control: ×
Leather steering wheel: ✓
Leather seats: —
Power front seat: ×
Power rear seat: ×
Wood panel: ×
Sunroof: ◯
Alloy wheels: 17 inches standard
Folding seat: split
Glass w/ UV filter: ×
Toned glasses: ×

Engine

Model: ----
Type: inline 4 cylinder DOHC
Bore x stroke, mm: 86.0x94.6
Engine size, cc: 2198
Compression ratio: 12.0
Fuel injection: 電子制御燃料噴射
Max power, hp/rpm: 155ps(114kW)/5600rpm
Max torque, Nm/rpm: ----kg m(220N m)/3800rpm
Supercharger: ×
Fuel tank, liters: 60 l
Fuel: Unleaded premium gasoline
Fuel consumption, l/100km: 0

Steering & suspension

Steering: Power assist equipped rack&pinion
Front suspension: McPherson Strut
Rear suspension: 4リンク
Front brake: Ventilated disk
Rear brake: disk
Front wheel: 215/50R17 91W
Rear wheel: 215/50R17 91W
Min turn diameter, m: ----

Gearbox

Number of stages: 5AT
Drive: FF
LSD: ----

Exterior equipment

Front fog lights: ✓
Rear fog lights: ✓
Xenon: ×
Extra front lights: ×
Spoilers (f / r): × / ×
Wiper: ✓

Navigation & sound

Navigation: ◯
Navigation device: DVD
Audio: AM/FM radio with MD player
CD player: 連装

Gear ratios

CVT	1	2	3	4	5	6	7	Rev	Main
—	4.685	2.942	1.923	1.301	1.000	—	—	—	3.177

Available colors

black / Other blackwhitegreen / Other greenMaroon (brown)OliveNavy blue / Other Navy bluePurpleAshesYellowYellow-greenBlack (P)MagentaSilver / Other SilverRedBlueDark cyanPearlGold
